Product |
Product id
| 952145
|
Brand
| AsusTek
|
Partnr
| 90IG08C0-MO3B00
|
EAN/UPC code
| 4711387094037
|
Warranty (months)
| 24 months
|
WAN connection |
Ethernet WAN
| Y
|
SIM card slot
| N
|
3G/4G USB modem compatibility
| Y
|
Network |
Networking standards
| IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
|
Ethernet interface type
| Gigabit Ethernet
|
VLAN support
| Y
|
Static route
| Y
|
Traffic control
| Y
|
Port forwarding
| Y
|
Mobile network |
Mobile network generation
| 5G
|
4G standard
| LTE
|
Management features |
Web-based management
| Y
|
Quality of Service (QoS) support
| Y
|
Wake-on-LAN ready
| Y
|
Reset button
| Y
|
Ports & interfaces |
Ethernet LAN (RJ-45) ports
| 8
|
WAN/Ethernet LAN ports quantity
| 2
|
WAN ports quantity
| 1
|
USB ports quantity
| 1
|
USB version
| 3.2 Gen 1 (3.1 Gen 1)
|
Packaging data |
AC adapter included
| Y
|
Cables included
| LAN (RJ-45)
|
Quick start guide
| Y
|
Package width
| 281 mm
|
Package depth
| 194 mm
|
Package height
| 94 mm
|
Package weight
| 1900 g
|
Package type
| Box
|
Protocols |
DHCP server
| Y
|
DMZ support
| Y
|
Security |
Security algorithms
| IPSec, SSH
|
Firewall
| Y
|
Access Control List (ACL)
| Y
|
Guest access
| Y
|
Firewall security
| Maximum Firewall Keyword Filter :64 • Maximum Firewall Network Service Filter :32 • Maximum Firewall URL Filter : 64
|
System event log
| Y
|
VPN support
| VPN Client L2PT
VPN Client Open VPN
VPN Client PPTP
VPN Client WireGuard
VPN Server IPSec
VPN Server Open VPN
VPN Server PPTP
VPN Server WireGuard
VPN Fusion
Support Surfshark
|
NAT functionality
| PPTP Pass-Through
• L2TP Pass-Through
• IPSec Pass-Through
• RTSP Pass-Through
• H.323 Pass-Through
• PPPoE Relay
|
Technical details |
Firmware upgradeable
| Y
|
Features |
Built-in processor
| Y
|
Processor frequency
| 1800 MHz
|
Processor manufacturer
| ARM
|
Processor model
| ARMv8
|
Flash memory
| 256 MB
|
Internal memory
| 512 MB
|
Design |
Product colour
| White
|
LED indicators
| Power, USB
|
Antenna |
Antenna type
| Internal
|
Antennas quantity
| 1
|
Power |
AC input voltage
| 110 - 240 V
|
AC input frequency
| 50/60 Hz
|
Output voltage
| 54 V
|
Output current
| 2.278 A
|
Power consumption (typical)
| 123 W
|
Power over Ethernet (PoE)
| Y
|
Weight & dimensions |
Width
| 212 mm
|
Depth
| 95 mm
|
Height
| 26 mm
|
Weight
| 530 g
|
