The ATEN Professional Online UPS is an exceptional and innovative electrical apparatus that provides emergency power to a load when the input power source, or the mains, fails. The basic technology of an online UPS is the same as in a standby or line-interactive UPS, however, the ATEN Professional Online UPS provides a much greater current of AC-to-DC battery-charger/rectifier where the rectifier and inverter are designed to run continuously with improved cooling systems.
1x Online UPS
1x Rack Mounting Kit
1x Rail Slide Kit
1x RS-232 Cable
1x USB Type A to B Cable
4x Power Cables
1x Tower Stand set
1x User Instructions

Specification

Product
Product id	795151
Brand	Aten
Partnr	OL1000HV-AT-G
EAN/UPC code	4719264647963
Power
Input frequency	40 - 70 Hz
Features
UPS topology	Double-conversion (Online)
Output power capacity	1 VA
Output power	1000 W
Waveform	Sine
Input operation voltage (min)	110 V
Input operation voltage (max)	300 V
Output operation voltage (min)	220 V
Output operation voltage (max)	240 V
Response time	4 ms
Efficiency	88 procent
Efficiency (ECO mode)	96 procent
Crest factor	3:1
ECO mode	Y
Noise level	50 dB
Ports & interfaces
AC outlet types	C13 coupler
Power plug	C14 coupler
AC outlets quantity	8 AC-uitgang(en)
USB port	Y
USB port type	USB Type-B
USB 2.0 ports quantity	1
Serial interface	Y
Serial interface type	RS-232
RS-232 ports	1
Serial ports quantity	1
Ethernet LAN (RJ-45) ports	2
Battery
Battery technology	Sealed Lead Acid (VRLA)
Battery capacity	9 Ah
Battery voltage	12 V
Number of battery cells	2
Typical backup time at full load	2.95 min
Typical backup time at half load	10.1 min
Battery recharge time	3 uur
Charging current	2 A
Cold start	Y
Design
Form factor	Rackmount/Tower
Product colour	Black
Rack capacity	2U
Cooling type	Active
Built-in fan	Y
LED indicators	Y
Certification	CE RoHS
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	20 - 90 procent
Storage relative humidity (H-H)	10 - 95 procent
Packaging data
Cables included	Output power cable, Power load cable, RS-232, USB cable
Manual	Y
Package width	88 mm
Package depth	438 mm
Package height	410 mm
Package weight	18500 g
Weight & dimensions
Width	88 mm
Depth	438 mm
Height	410 mm
Weight	13440 g
Logistics data
Master (outer) case net weight	13440 g
Master (outer) case width	240 mm
Master (outer) case length	500 mm
Master (outer) case height	600 mm
Master (outer) case weight	18500 g
Quantity per master (outer) case	1 stuk(s)
