What This Product Does

TP-LINK’s TL-WPA4226KIT AV500 Powerline WiFi Kit extends your Internet connection to every room of the house through your home’s existing electrical circuitry. The TL-WPA4220 features a Wi-Fi Clone Button which can automatically extend your router’s wireless signal, making it easy to realize seamless roaming within your home network. What’s more, TL-PA4020P has an integrated power socket, which allows an additional device or power bar to be connected to the adapter as though it were a normal wall socket.

One Touch Super Range Extension

With a Wi-Fi Clone Button enabling Super Range Extension, the TL-WPA4220 can automatically copy the wireless network name (SSID) and Password of your router at the push of a button. After pressing the button, you can place the powerline extender anywhere you want wired or wireless access and enjoy seamless networking across your entire home or office.

Up to 500Mbps - Ideal for HD Video Streaming

With advanced HomePlug AV technology, TL-WPA4226KIT provides you with stable, high-speed data transfer rates of up to 500Mbps on a line length of up to 300 meters. It is a great choice for a whole home solution to connect all network compatible devices - from computers, game consoles to set-top boxes for IPTV to printers and NAS hard drives.

Extend Wi-Fi Coverage to Every Room

With wireless speeds of up to 300Mbps, you can effortlessly extend your Wi-Fi network via the existing powerline and broadcast a wireless signal to share with all your Wi-Fi enabled devices in another area of your home or office.

Extra Power Socket for Additional Devices

With TL-PA4020P’s integrated power socket, the new TL-WPA4226KIT provides real convenience for your home network. The integrated power socket allows an additional device or power bar to be connected to the adapter as though it were a normal wall socket. This ensures that even with the TL-PA4020P plugged in, no power outlet is going to waste.

Plug and Play

You can set up a hassle-free powerline network within minutes with TP-LINK’s powerline adapters, just plug in and play. Also, the adapters’ “Pair” buttons can be utilized for securing or managing multiple powerline adapters in your home powerline network.
1. Plug one Internet connected adapter into a nearby power outlet.
2. Connect additional adapters to PCs/laptops/Internet TVs or other networked devices via an Ethernet cable or Wi-Fi, and you're done!

*Recommended: Press the pair buttons for network security and data encryption.

Specification

Product
Product id	448590
Brand	TP-Link
Partnr	TL-WPA4226KIT
EAN/UPC code	6935364032739
Performance
Maximum data transfer rate	600 Mbit/s
Ethernet LAN	Y
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN data rates	10, 100 Mbit/s
Wi-Fi	Y
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rates supported	600 Mbit/s
Networking standards	IEEE 1901, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Built-in power socket	Y
PowerLine standard	HomePlug AV
Modulation	OFDM
Security algorithms	128-bit AES, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Plug and Play	Y
Technical details
Maximum operating distance	300 m
Sustainability certificates	RoHS
Design
Antenna type	Internal
LED indicators	LAN, PLC, Power, WLAN
Product colour	White
Certification	CE, FCC, RoHS
System requirements
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Linux operating systems supported	Y
Mac operating systems supported	Y
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 procent
Storage relative humidity (H-H)	5 - 90 procent
Packaging content
Quantity per pack	2 stuk(s)
Quick installation guide	Y
Cables included	LAN (RJ-45)
Package type	Box
