Enhance your workspace: the AM420B dual arm - Seamlessly integrate, maximize space, and manage cables.
The AM420B is an embodiment of precision and strength. Crafted to perfection with an aluminum alloy build, the dual arm accommodates monitor sizes from 17” to 34”, with a maximum weight capacity of 9 kg. Its durable mechanical spring mechanism ensures sturdy support, while VESA compatibility (75x75, 100x100mm) allows for easy integration. Enjoy a versatile range of motion, including up to 495 mm height adjustment, up to 456 mm extension, -15°/90° tilt, -90°/90° swivel, and 360° pivot range, enhancing your workspace flexibility. Select between C Clamp or Grommet installation methods to suit your setup and elevate your ergonomic experience with the dual arm AM420B.

Specification

Product
Product id	950488
Brand	AOC
Partnr	AM420B
EAN/UPC code	4038986631372
Mounting
Maximum weight capacity	9 kg
Maximum weight capacity (per display)	9 kg
Minimum screen size compatibility	17 "
Maximum screen size	34
Mounting type	Desk
Mounting	Clamp/Bolt-through
Minimum VESA mount	75 x 75 mm
Maximum VESA mount	100 x 100 mm
Panel mounting interface	75 x 75, 100 x 100 mm
Number of displays supported	2
Ergonomics
Depth adjustment range	0 - 455 mm
Tilt angle range	-15 - 90 °
Swivelling	Y
Swivel angle range	-90 - 90 °
Pivot angle	0 - 360 °
Number of arms	2
Cable management	Y
Tilt adjustment	Y
Design
Product colour	Black
Housing material	Aluminium
Packaging content
Clamp included	Y
Mounting kit	Y
Manual	Y
Packaging content	User Manual, Monitor Arm, Clamp mount, Grommet mount, Installation materials
Weight & dimensions
Weight	4.6 g
Package width	112 mm
Package depth	324 mm
Package height	91 mm
Package weight	5500 g
Package type	Box
Packaging data
Quantity per pack	1 stuk(s)
Other features
Height (max)	495 mm
