Product |
Product id
| 967707
|
Brand
| AsusTek
|
Partnr
| 90IG0950-MO9A0V
|
EAN/UPC code
| 4711387580660
|
Warranty (months)
| 36 months
|
Packaging content |
Packaging content
| RT-BE92U WiFi 7 Tri-band Router
wall mount kit
RJ-45 cable
Power Adapter
Quick Start Guide
Warranty Card
|
WAN connection |
Ethernet WAN
| Y
|
DSL WAN
| N
|
SIM card slot
| N
|
3G/4G USB modem compatibility
| N
|
WAN connection type
| RJ-45
|
Wireless LAN features |
Wi-Fi band
| Tri-band (2.4 GHz / 5 GHz / 6 GHz)
|
Top Wi-Fi standard
| Wi-Fi 7 (802.11be)
|
WLAN data transfer rate (max)
| 5764 Mbit/s
|
Wi-Fi standards
| 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
|
WLAN data transfer rate (first band)
| 1032 Mbit/s
|
WLAN data transfer rate (second band)
| 2882 Mbit/s
|
WLAN data transfer rate (third band)
| 5764 Mbit/s
|
Network |
Ethernet LAN
| Y
|
Ethernet LAN interface type
| 10 Gigabit Ethernet
|
Ethernet LAN data rates
| 10, 100, 1000, 2500, 10000 Mbit/s
|
Networking standards
| IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n
|
Port forwarding
| Y
|
Port triggering
| Y
|
Dynamic DNS (DDNS)
| Y
|
Support Samba (storage)
| Y
|
VPN server
| VPN Server IPSec, VPN Server Open VPN, VPN Server PPTP, VPN Server WireGuard
|
Media server
| Y
|
Ports & interfaces |
Ethernet LAN (RJ-45) ports
| 3
|
USB port
| Y
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
| 1
|
DC-in jack
| Y
|
Management features |
Web-based management
| Y
|
Bandwidth control
| Y
|
Quality of Service (QoS) support
| Y
|
Wake-on-LAN ready
| Y
|
Reset button
| Y
|
WPS push button
| Y
|
Intelligent Mesh technology
| Y
|
MU-MIMO technology
| Y
|
Security |
Security algorithms
| WPA, WPA2, WPA3-Personal
|
Firewall
| Y
|
Guest access
| Y
|
Parental control
| Y
|
Filtering
| Y
|
MAC address table
| 64 entries
|
MAC address filtering
| Y
|
URL filtering
| Y
|
DMZ support
| Y
|
Network address translation (NAT)
| Y
|
NAT functionality
| PPTP Pass-Through
L2TP Pass-Through
IPSec Pass-Through
RTSP Pass-Through
H.323 Pass-Through
SIP Pass-Through
PPPoE Relay
|
Protocols |
DHCP server
| Y
|
Design |
Product type
| Tabletop router
|
Product colour
| Black
|
Wall mountable
| Y
|
Indication light
| Y
|
LED indicators
| LAN, Power, WAN
|
On/off switch
| Y
|
Antenna |
Antenna design
| External
|
Antennas quantity
| 4
|
Features |
Built-in processor
| Y
|
Processor frequency
| 2 MHz
|
Processor cores
| 4
|
Internal memory
| 1000 MB
|
Internal memory type
| DDR4
|
Flash memory
| 256 MB
|
Firmware upgradeable
| Y
|
Power |
Power source type
| DC
|
AC input voltage
| 110 - 240 V
|
AC input frequency
| 50/60 Hz
|
Output voltage
| 12 V
|
Output current
| 3 A
|
Weight & dimensions |
Width
| 247.18 mm
|
Depth
| 101.59 mm
|
Height
| 287.47 mm
|
Weight
| 790 g
|
Package width
| 374 mm
|
Package depth
| 219 mm
|
Package height
| 105 mm
|
Package weight
| 2100 g
|
Packaging data |
Cables included
| LAN (RJ-45)
|
AC adapter included
| Y
|
Warranty card
| Y
|
Quick start guide
| Y
|
Package type
| Box
|
