PCIe 5.0 Ready
Faster storage, graphics and networking capabilities
PCI Express® (PCIe®) 5.0 delivers 32GT/s bandwidth, which is twice the speed of PCIe 4.0, and offers lower power consumption, better land scalability and backwards compatibility. ASUS servers are PCIe 5.0 ready with scalability design to satisfy the increasing workloads for modern data center.

AMD EPYC™ 9004 Series Processors
The 9004 Series EPYC CPUs amplifies the AMD history of x86 architecture innovations and record-breaking performance with next generation 5nm technology as well as introducing support for high performant DDR5 DIMMs and fast PCIe® Gen 5 I/O. EPYC 9004 CPUs support 12 memory channels with 2 DIMMs/channel capability, delivering the resources needed for memory hungry AI, ML, HPC, and large in-memory computations.

Specification

Product
Product id	998853
Brand	AsusTek
Partnr	90SF02E1-M005U0
EAN/UPC code	4711387172674
Processor
Processor socket	Socket SP5
Processor manufacturer	AMD
Processor family	AMD EPYC
Number of processors supported	2
Compatible processor series	AMD EPYC 9004
Memory
Number of DIMM slots	24
Supported memory types	DDR5-SDRAM
Supported DIMM module capacities	128GB, 64GB, 32GB
Maximum internal memory	6144 GB
Supported RDIMM clock speeds	4400, 4800 MHz
Storage
Number of storage drives supported	16
Hot-swap HDD bays	Y
Number of 2.5" bays	2
Number of 3.5" bays	12
Storage drive sizes supported	2.5, 3.5, M.2 "
Supported storage drive types	HDD & SSD
SSD form factor	M.2
Graphics
On-board graphics adapter model	Aspeed AST2600
On-board graphics adapter memory	64 MB
Network
Ethernet LAN	Y
Ethernet interface type	10 Gigabit Ethernet
LAN controller	Intel X710-AT2
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Ethernet LAN (RJ-45) ports	2
IPMI LAN (RJ-45) port	Y
VGA (D-Sub) ports quantity	1
Expansion slots
PCI Express slots version	5.0
Features
Trusted Platform Module (TPM)	Y
Trusted Platform Module (TPM) version	2.0
Technical details
Compliance certificates	BSMI, CE, CB, C-TICK, Federal Communications Commission (FCC)
Design
Chassis type	Rack (2U)
Product colour	Grey
LED indicators	Y
On/off switch	Y
Reset button	Y
Number of fans	4 ventilator(en)
Power
Power supply	2600 W
Redundant power supply (RPS) support	Y
Operational conditions
Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-40 - 60 °C
Storage relative humidity (H-H)	20 - 90 procent
Weight & dimensions
Width	449 mm
Depth	840 mm
Height	88.1 mm
Weight	19300 g
Packaging data
Package weight	25770 g
