TUF Gaming Gold EVO Series
Built For The Long Haul
The ASUS TUF Gaming 750W Gold EVO packs military-grade strength, a flagship fan design, and PCB protection for efficient, durable power delivery. The result is a PSU that can reliably fuel your rig for years to come.

Specification

Product
Product id	1009720
Brand	AsusTek
Partnr	90YE00SB-B0NA00
EAN/UPC code	4711636287876
Warranty (months)	8-year warranty is included.
Endurance
Mean time between failures (MTBF)	120000 uur
Power
Total power	750 W
AC input voltage	100 - 240 V
Power Factor Correction (PFC) type	Active
Combined power (+3.3V)	110 W
Combined power (+12V)	750 W
Combined power (+5V)	110 W
Combined power (-12V)	3.6 W
Combined power (+5Vsb)	15 W
Max output current (+3.3V)	20 A
Max output current (+12V)	62.5 A
Max output current (+5V)	20 A
Max output current (-12V)	0.3 A
Max output current (+5Vsb)	3 A
Power protection features	Overheating, Over current, Over power, Under voltage, Over voltage, Short circuit
Ports & interfaces
Motherboard power connector	20+4 pin ATX
Motherboard power cable length	500 mm
Number of SATA power connectors	4
SATA power cable length	400, 120 mm
Peripheral (Molex) power connectors (4-pin)	2
Peripheral (Molex) power cable length	400, 120 mm
PCI Express power connectors (6+2 pin)	2
PCI Express power connectors (16-pin)	1
CPU power connector (4+4 pin)	Y
Cabling type	Fully-Modular
Performance
Purpose	PC
Power supply unit (PSU) form factor	ATX
80 PLUS certification	80 PLUS Gold
ATX version	3.1
Bearing technology	DBB
Design
Product colour	Black
Cooling type	Active
Number of fans	1 ventilator(en)
Fan location	Top
On/off switch	Y
Weight & dimensions
Width	140 mm
Depth	150 mm
Height	86 mm
Weight	1320 g
Packaging data
Cables included	CPU, PCIe, Peripheral (Molex), SATA
Package width	320 mm
Package depth	182 mm
Package height	127 mm
Package weight	2060 g
Package type	Box
