2-CH Dante Expansion Card for AP Series



Aten
Not in stock
€ 298,62
€ 361,33 incl 21% VAT
Dedicated for use with ATEN’s AP DSP Power Amplifier series, the AP901 allows the AP amplifiers to receive 2 inputs of high-quality, low-latency digital audio via the Dante® AoIP solution. The range of Dantebased applications are broadened thanks to the easy integration with various Dante-enabled equipment, from digital mixers, DSPs, and more, brought by the AP901 working in conjunction with the AP amplifiers. The AP901 delivers industry standard audio quality at 24-bit depth and supports sampling rates of 44.1 / 48 kHz, ensuring excellent audio integrity while fulfilling different environment needs. The installation into the AP power amplifiers’ expansion slot is easy. With all the Danteenabled devices being manageable and configurable fully through the Dante Controller software, the utilization of AP901 helps further enhance flexibility and streamline workflows in any Dante network infrastructure including broadcasting, recording, and other professional audio distribution scenarios. Furthermore, with just one Ethernet cable and some simple mouse clicks, ATEN’s Dante networking technology eliminates the need for traditional analog cables, expanding Dante network coverage and distributing AV signals across multiple locations at once.

Specification

Product
Product id 959656
Brand Aten
Partnr AP901-AT
EAN/UPC code 4710469348709
Warranty (months) 3 years
Audio
Audio output channels 2.0 kanalen
Ports & interfaces
Ethernet LAN data rates 10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports 1
Technical details
Connectivity technology Wired
Product colour Black, Metallic
Material Metal
Country of origin Taiwan
Weight & dimensions
Width 22 mm
Depth 115 mm
Height 110 mm
Weight 120 g
Operational conditions
Operating temperature (T-T) 0 - 50 °C
Storage temperature (T-T) -20 - 60 °C
Operating relative humidity (H-H) 0 - 80 procent
Certificates
Certification FCC, CE, UKCA
Logistics data
Master (outer) case width 270 mm
Harmonized System (HS) code 85184000
Master (outer) case length 470 mm
Master (outer) case height 296 mm
Master (outer) case weight 2000 g
Packaging data
Package weight 180 g
Package width 124 mm
Package depth 129 mm
Package height 42 mm
