The ATEN CN800 offers superior video quality with HD resolutions up to 1920 x 1200 @ 60 Hz, facilitating easier KVM access. The CN800 USB VGA KVM over IP Mini provides "over-IP" access control for conventional KVM switches lacking built-in over-IP functionality. It enables system operators to monitor and access computers remotely using Windows and Java-based application programs. The CN800 connects to an intranet, either LAN or WAN simply by using an industry-standard Cat 5e/6 cable and to a target computer or server. WinClient and JavaClient are available for remote access, enabling IP connection and login from anywhere over the internet.

The ATEN CN800 uses the standard TCP/IP protocols for communication. It allows the connected server or computer to be accessed from any computer over the internet – whether that computer is located down the hall, in other areas of the country, or branch offices in other parts of the world. The CN800 provides a fast, reliable, and cost-effective way to remotely access and manage widely distributed multiple computer installations.

Specification

Product
Product id	995581
Brand	Aten
Partnr	CN800-AT
EAN/UPC code	4710469349812
Ports & interfaces
Keyboard port type	USB
Mouse port type	USB
Network
Ethernet LAN	Y
Ethernet LAN (RJ-45) ports	1
Performance
Maximum resolution	1920 x 1200 Pixels
Design
Product colour	Black, Purple
Housing material	Plastic
LED indicators	Y
Display
Built-in display	N
Power
Power source	DC
Power consumption (typical)	3.47 W
Features
Country of origin	Taiwan
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80 procent
Weight & dimensions
Width	56.6 mm
Depth	93.2 mm
Height	24.4 mm
Weight	170 g
Logistics data
Harmonized System (HS) code	84718000
