1x CS22H 2-Port USB 4K HDMI Cable KVM Switch
1x User Instructions

Specification

Product
Product id	721804
Brand	Aten
Partnr	CS22H-AT
EAN/UPC code	4710469340468
Ports & interfaces
Number of computers controlled	2
Keyboard port type	USB
Mouse port type	USB
Video port type	HDMI
HDMI ports quantity	3
Console ports	3.5mm headphone, 3.5mm mic, HDMI, USB A
Console USB ports quantity	2
Audio connections	Y
Headphone outputs	3
Number of microphone inputs	3
Performance
HD type	4K Ultra HD
Maximum resolution	4096 x 2160 Pixels
Video bandwidth	60 Hz
Design
Rack mounting	N
Product colour	Black
Housing material	Plastic
LED indicators	Y
Display
Built-in display	N
Power
Power source	DC
DC input voltage	5 V
Power consumption (typical)	3.47 W
Packaging data
Package width	55 mm
Package depth	155 mm
Package height	223 mm
Package weight	420 g
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80 procent
Storage relative humidity (H-H)	0 - 80 procent
Weight & dimensions
Width	83.4 mm
Depth	84.2 mm
Height	30.4 mm
Weight	340 g
Packaging content
Quick installation guide	Y
Logistics data
Master (outer) case net weight	6800 g
Master (outer) case width	328 mm
Master (outer) case length	389 mm
Master (outer) case height	330 mm
Master (outer) case weight	9300 g
Quantity per master (outer) case	20 stuk(s)
