Clear High-Definition Video
Delivering crisp, high-definition video to ensure every frame is sharp, vivid, and reliable in any environment

Intelligent Video Analytics
Advanced video analytics reduce false alarms to deliver real-time precision and smarter, proactive monitoring

Simplified Cabling Installation
PoE enabling both power and data transmission through a single cable, reducing installation complexity and cost

IK10 Protection
Achieves the highest impact rating (IK10), making the camera impervious to heavy blows and attempted vandalism

Digital Wide Dynamic Range
Precisely capture objects in challenging environments, ensuring optimal visibility in both bright highlights and deep shadows

IP66 Weather-Proof
IP66-rated weatherproofing guarantees durability against dust and water jets, even in the harshest outdoor conditions

See Everything, Miss Nothing
Experience every detail in stunning high definition. Engineered for professional-grade clarity, the BCD-P01 delivers a crisp, consistent view of your business premises around the clock. By capturing high-fidelity footage that reveals critical evidence when it matters most, the BCD-P01 ensures your operations are protected with absolute visual integrity.

Smart Event Detection
Transform your surveillance from passive recording to proactive protection. The BCD-P01 features built-in Intelligent Video Analytics that go beyond simple motion detection, identifying specific events and behaviors in real-time. By filtering out environmental noise, it delivers the precise insights needed to enhance site safety and operational efficiency.

Single-Cable Integration
Streamline the setup with PoE. By integrating power and data into a single cable, the BCD-P01 eliminates cable clutter and significantly reduces the infrastructure costs and labor time required for traditional power configurations.

Vandal-Proof IK10 Protection
Built for the toughest environments. With the highest industry-standard IK10 impact rating, the BCD-P01 is engineered to withstand heavy physical blows and targeted vandalism. Ensure uninterrupted surveillance and protect your security investment with a housing designed for absolute durability.

Specification

Product
Product id	1025655
Brand	D-Link
Partnr	BCD-P01
EAN/UPC code	790069482199
Performance
Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Y
Design
Form factor	Dome
Mounting type	Ceiling
Product colour	White
International Protection (IP) code	IP66
Camera
Angle of rotation	350 °
Lens viewing angle, horizontal	93.1 °
Lens viewing angle, vertical	52.2 °
Tilt angle range	0 - 75 °
Pan range	0 - 355 °
Image sensor
Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/3 "
Progressive scan	Y
Lens system
Number of lenses	1
Maximum aperture number	2
Fixed focal length	2.8 mm
Night vision
Night vision	Y
Night vision distance	30 m
LED type	IR
Number of illumination LEDs	4
Video
Maximum resolution	1920 x 1080 Pixels
Total megapixels	2 MP
Video formats supported	H.264, H.265
Video compression formats	H.264, H.265
Supported graphics resolutions	1920 x 1080 (HD 1080)
Supported video modes	1080p
Video recording	Y
Video streaming	Y
Gain control type	Auto
Highlight Compensation (HLC)	Y
Frame rate	30 fps
Back Light Compensation (BLC)	Y
Audio
Built-in microphone	Y
Network
Ethernet LAN	Y
Wi-Fi	N
Bluetooth	N
Ethernet interface type	Fast Ethernet
Networking standards	IEEE 802.3af
Supported network protocols	IPv4/IPv6; HTTP/HTTPS; RTSP/RTP/RTCP; TCP/UDP; DHCP; DNS; DDNS; UPnP; PPPoE; NTP; FTP; SMTP Client; 802.1x; SNMP; ONVIF Profile S/T compliant; ICMP; IGMP
Storage
Built-in HDD	N
Card reader integrated	Y
Compatible memory cards	MicroSD (TransFlash)
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Security
Video motion detection	Y
Management features
Cloud-managed	Y
Reset button	Y
Power
Power source type	DC, PoE
Power consumption (Power over Ethernet (PoE))	4.4 W
DC output voltage	12
Operational conditions
Operating temperature (T-T)	-25 - 55 °C
Storage temperature (T-T)	-25 - 55 °C
Operating relative humidity (H-H)	0 - 90 procent
Storage relative humidity (H-H)	0 - 90 procent
Weight & dimensions
Height	85.4 mm
Diameter	110 mm
Weight	405 g
Packaging content
Number of cameras	1
