Advanced Security Features
The DGS-1100 series’ web user interface gives administrators an easy way to manage Layer 2 features, such as VLANs, Spanning Tree Protocol (STP), and link aggregation (desktop models utilize Static Trunk). With powerful security features including IGMP snooping, Static MAC, and Storm Control, these smart managed switches are a versatile solution for deployments that require easy to configure functionality without added complexities.

Simplify Network Management
D-Link’s free Network Assistant (DNA) utility displays all your connected devices and makes first-time configuration a breeze. The free D-View 7 Network Management System comes with a license for 25 nodes and 2 probes and full access to the management tools.

Easy Troubleshooting
The DGS-1100 Series features Loopback Detection and Cable Diagnostics to help network administrators find and solve network problems quickly and easily.
Loopback Detection detects loops created by a specific port and automatically shuts down the affected port. The Cable Diagnostics feature is designed for network administrators to quickly examine the quality of the copper cables, recognize the cable type, and detect cable errors.

Green Technology
D-Link Green technology enables the DGS-1100 Smart Managed Switches to save power without sacrificing performance. The desktop models in the series utilize a fanless design, for silent and energy-efficient operation. All models are also IEEE 802.3az-compliant and feature Link Status detection.

Specification

Product
Product id	707337
Brand	D-Link
Partnr	DGS-1100-08V2/E
EAN/UPC code	790069453410
Data transmission
Switching capacity	16 Gbit/s
Forwarding rate	11.9 Mpps
Packet buffer memory	0.187 MB
Network
Copper ethernet cabling technology	1000BASE-T
Auto MDI/MDI-X	Y
Management features
Switch type	Managed
Switch layer	L2
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Weight & dimensions
Width	145 mm
Depth	28 mm
Height	82 mm
Weight	340 g
Power
AC input voltage	100 - 240 V
DC input voltage	5 V
Input current	1 A
Power consumption (max)	4.94 W
Design
Rack mounting	N
Product colour	Black
Reset button	Y
Operational conditions
Operating altitude	0 - 2000 m
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	0 - 95 procent
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 procent
Performance
Fanless	Y
Harmonized System (HS) code	85176990
Power over Ethernet (PoE)
Power over Ethernet (PoE)	N
