Powerful Switching for your Business
The DGS-1100 Series is a range of powerful switches that offer a lot of bang for your buck. They are great for busy SMBs who expect a lot of their network, including support for surveillance and VoIP. They are packed with traffic management & optimization features that keep your network congestion free. Meanwhile, management tools are flexible and intuitive, making your life easier.

Easy to Use & Easy to Install
D-Link Network Assistant Utility (DNA) can quickly discover and do initial setup for D-Link Networking devices such as the DGS-1100 Series, which greatly improves efficiency for solution deployment.

VLANs: Stronger Security & Better Traffic Management
Relatively easy to set up, VLANs can be a big boon for your network. They can isolate sensitive areas of your network, keeping them safe from those with malicious intent, or keeping bandwidth open for latency-sensitive traffic such as VoIP.

Green Technology
D-Link Green technology enables the DGS-1100 Smart Managed Switches to save power without sacrificing performance. Most of the models in the series utilize a fanless design, for silent and energy-efficient operation. All are IEEE 802.3az-compliant and feature Link Status detection and Time-Based PoE.

PD Alive Actively Mitigates Downtime
Round-the-clock surveillance footage is vital. If you have Cameras attached to your network,
you may have thought technical difficulties were a given. However, the PD-Alive feature actively mitigates device downtime. If a device is not working as expected, the Switch can automatically reset them and get them back online. No need to turn them on and off again in the middle
of the night.

Specification

Product
Product id	1013081
Brand	D-Link
Partnr	DGS-1100-18PV2
EAN/UPC code	790069453366
Data transmission
Switching capacity	36 Gbit/s
Forwarding rate	26.78 Mpps
Jumbo frames support	Y
Jumbo frames	9216
Network
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x
10G support	N
Copper ethernet cabling technology	1000BASE-T
Half duplex	Y
Full duplex	Y
Flow control support	Y
Auto-negotiation	Y
Auto MDI/MDI-X	Y
Spanning tree protocol	Y
Link aggregation	Y
Ethernet LAN data rates	10, 100, 1000 Mbit/s
VLAN support	Y
Number of VLANs	4094
Management features
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	16
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity	2
Security
IGMP snooping	Y
Weight & dimensions
Width	280 mm
Depth	230 mm
Height	44 mm
Weight	2100 g
Power
Power source	DC/PoE
Power supply included	Y
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Endurance
Mean time between failures (MTBF)	343695 uur
Design
Rack mounting	Y
Form factor	1U
Product colour	Black
Number of fans	1 ventilator(en)
Electromagnetic compatibility	FCC Class A, CE Class A, VCCI Class A, C-Tick, BSMI
Certification	cUL, UL, LVD, CB, BSMI
Operational conditions
Heat dissipation	125.2 BTU/h
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	0 - 95 procent
Operating temperature (T-T)	-5 - 50 °C
Operating relative humidity (H-H)	0 - 95 procent
Performance
Noise level	45.8 dB
Technical details
Compliance certificates	RoHS
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet (PoE) ports quantity	16
Total Power over Ethernet (PoE) budget	130 W
