Accelerate your network with Multi-Gigabit Ethernet.
With two 10GBASE-T ports and four 10G/25G SFP28 ports, up to 400Gbps switching capacity, physical stacking of up to 9 switches for greater port density, and Layer 2 and Layer 3 features, the DMS-3130 Switch Series offer a versatile, secure, and fast network that can be deployed in a variety of environments and topologies, including Metro Ethernet deployments.

World-class reliability.
Advanced L2 and L3 features including port security, Storm Control, Link Aggregation, and Spanning Tree Protocols. Management options like 802.3ah OAM, 802.1ag CFM, and industry standard CLI support, with support for multiple images and multiple configurations.

x4 25G SFP28 uplink ports, physical stacking for redundancy, and have built-in G.8032 Ethernet Ring Protection Switching (ERPS) to help minimise recovery times to 50 ms. An USB 2.0 interface to store config files, boot images, and syslog. As well as support for an additional external redundant power supply on all models to ensure maximum uptime. DMS-3130-30PS even supports PoE PD function on the MGMT port, allowing it to be powered by a PoE switch.

Comprehensive security.
Includes the latest security such as Multi-layer and Packet Content Access Control Lists (ACL), and Storm Control. And our exclusive D-Link Safeguard Engine has been designed to guard against traffic flooding caused by malicious attacks and protect your business network uptime.

IP-MAC-Port Binding allows you to bind a source IP address with an associated MAC and define the port number to enhance user access control. And DHCP Snooping makes the switch learn IP/MAC pairs by snooping DHCP packets and saving them to the IMPB whitelist, giving you extra control.

Electrical surge protection.
Featuring built-in 6 kV surge protection on all PoE and non-PoE 2.5G/5G Ethernet access ports, the switches are protected against sudden electrical surges caused by lightning strikes or unstable electrical currents. It lowers maintenance costs effectively by minimising the need for expensive equipment repairs or replacements.

Easy Access Control policies.
They feature multiple authentication mechanisms such as 802.1X, Web-based Access Control (WAC), and MAC-based Access Control (MAC) for strict access control and an easy deployment. After authentication, individual policies such as VLAN membership, Quality of Service (QoS) policies, and ACL rules can be assigned to each host.

A stack above the competition.
Unlock the full potential of your network infrastructure. Utilise the high switching capacity of up to 400Gbps to eliminate bottlenecks and maintain optimal network efficiency even during peak times, enabling you to effortlessly handle demanding network environments.

Versatile traffic management.
The DMS-3130 Series has a rich set of multi-layer QoS/CoS features to ensure that critical network services such as VoIP, video conferences, IPTV, and IP surveillance are always given high priority. L2/L3 Multicast support enables your network to handle growing IPTV applications.

PoE+ /PoE++ with budgets up to 960W
PoE+ /PoE++ with budgets up to 960W DMS-3130-30PS provides sixteen 2.5G ports supporting 802.3af/at PoE and eight 5G ports supporting 60W 802.3bt PoE standards with a power budget of 740 watts expandable to 960 watts with dual power supplies.

Multi-Gigabit PoE with up to 60W of power per port is ideal for Wi-Fi 6/6E access points, smart lighting, or industrial automation equipment. Perpetual PoE and Fast PoE support delivers faster and uninterrupted power to connected devices even when the switch is booting.

Specification

Product
Product id	905335
Brand	D-Link
Partnr	DMS-3130-30TS/E
EAN/UPC code	790069467554
Data transmission
MAC address table	32768 entries
Switching capacity	360 Gbit/s
Forwarding rate	268 Mpps
Number of queues	8
Jumbo frames support	Y
Jumbo frames	9000
Packet buffer memory	4 MB
Network
Networking standards	IEEE 802.11ad, IEEE 802.1ag, IEEE 802.3ah, IEEE 802.1p, IEEE 802.11d, IEEE 802.1s, IEEE 802.1AX, IEEE 802.3x, IEEE 802.1v, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1x
10G support	Y
Port mirroring	Y
Ethernet Ring Protection Switching (ERPS)	Y
Flow control support	Y
Fast leave	Y
Spanning tree protocol	Y
Broadcast storm control	Y
Link aggregation	Y
VLAN support	Y
Virtual LAN features	Protocol-based VLAN, MAC address-based VLAN, Port-based VLAN, Voice VLAN, Multicast VLAN, Private VLAN
Number of VLANs	4000
Management features
Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Y
Web-based management	Y
System event log	Y
Protocols
GARP VLAN Registration Protocol (GVRP)	Y
Routing protocols	OSPFv2, RIPng, OSPFv3, RIP-1, RIP-2
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	2
Basic switching RJ-45 Ethernet ports type	10G Ethernet (100/1000/10000)
10G Ethernet (copper) ports quantity	2
SFP module slots quantity	24
Console port	RJ-45
USB 2.0 ports quantity	1
Power connector	AC-in jack
Security
DHCP features	DHCP client, DHCP relay, DHCP server, DHCP snooping
Access Control List (ACL)	Y
Access Control List (ACL) egress	512
Access Control List (ACL) ingress	2048
IGMP entries	1024
IGMP snooping	Y
Queue scheduling algorithms	Weighted Round Robin (WRR), Weighted random early detection (WRED), Strict Priority Queue (SPQ)
Authentication type	RADIUS, TACACS+
Static port security	Y
SSH/SSL support	Y
Loop protection	Y
BPDU filtering/protection	Y
Authentication	Guest VLAN
Weight & dimensions
Width	440 mm
Depth	250 mm
Height	250 mm
Weight	3630 g
Power
Power source	AC
Power supply included	Y
Redundant power supply (RPS) support	Y
AC input voltage	100 - 240 V
Power consumption (max)	74.26 W
Surge protection	Y
Surge protection voltage	6 kV
Multicast features
Multicast support	Y
MLD entries	64
Endurance
Mean time between failures (MTBF)	270340 uur
Design
Rack mounting	Y
Stackable	Y
Form factor	Desktop/Wall-Mounting
Product colour	Black
Housing material	Metal
Number of fans	3 ventilator(en)
Safety	CB, cUL, BSMI, CCC
Certification	FCC Class A, CE Class A, VCCI Class A, IC, RCM, BSMI, CCC
Operational conditions
Heat dissipation	253.38 BTU/h
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90 procent
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 procent
Performance
Physical stacking (units)	9
Virtual stacking (units)	32
sFlow	Y
Noise level	52.5 dB
Power over Ethernet (PoE)
Power over Ethernet (PoE)	N
