The Conceptronic UPS provides long-lasting, reliable battery backup for the home or small office. The unit is simple to install and operate, offering an easy and safe way of protecting your systems from harmful power surges and failures. The UPS comes with modem/LAN protection, a powerful microprocessor and a fault indicator which warns against dangerous wiring. Stylish, compact design makes the UPS ideal for limited office and home working spaces.

Specification

Product
Product id	1012536
Brand	Conceptronic
Partnr	ZEUS03G
EAN/UPC code
Technical details
Harmonized System (HS) code	8504406090
Compliance certificates	CE, RoHS
Features
UPS topology	Line-Interactive
Output power capacity	1.2 VA
Output power	720 W
Input operation voltage (min)	220 V
Input operation voltage (max)	240 V
Output operation voltage (min)	220 V
Output operation voltage (max)	240 V
Automatic Voltage Regulation (AVR)	Y
Audible alarm(s)	Y
Audible alarm modes	Alarm when on battery, Fault, Low battery alarm, Overload alarm
Auto-restart	Y
Socket circuit breaker	Y
Country of origin	China
Ports & interfaces
AC outlet types	Type G (BS 1363)
AC outlets quantity	4 AC-uitgang(en)
USB port	Y
USB port type	USB Type-B
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Battery
Battery technology	Lead-acid
Battery capacity	14 Ah
Battery voltage	24 V
Number of batteries supported	2
Battery recharge time(90%)	8 uur
Battery capacity (Watt-hours)	168 Wh
Design
Form factor	Desktop
Product colour	Black
LED indicators	Y
International Protection (IP) code	IP20
Display type	LCD
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 procent
Packaging data
Cables included	USB cable
Quick installation guide	Y
Package width	255 mm
Package depth	376 mm
Package height	268 mm
Package weight	8237.5 g
Weight & dimensions
Width	148 mm
Depth	298 mm
Height	178 mm
Weight	7600 g
Logistics data
Master (outer) case width	272 mm
Pallet height	2037 mm
Master (outer) case length	397 mm
Master (outer) case height	293 mm
Pallet width	1200 mm
Master (outer) case weight	8805.5 g
Pallet length	800 mm
Quantity per master (outer) case	1 stuk(s)
