EnGenius Cloud Managed 11ac Wave 2 2×2 Outdoor Wireless Access Point ECW160 supports MU-MIMO wireless connection, providing up to 867 Mbps in the 5 GHz band and 400 Mbps in the 2.4 GHz band. Its IP67-rated weatherproof and dustproof housing withstands harsh environments, and its Mesh Wireless Support simplifies setup and self-heals. The EnGenius Cloud App allows remote management of an unlimited number of APs.

Specification

Product
Product id	987858
Brand	EnGenius
Partnr	ECW160
EAN/UPC code	EGS-ECW160
Warranty (months)	2 Years
Packaging data
Mounting kit	Y
Quick start guide	Y
Features
2.4 GHz	Y
5 GHz	Y
Maximum data transfer rate	867 Mbit/s
Maximum data transfer rate (2.4 GHz)	400 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Frequency band	2.4 - 2.482, 5.15 - 5.25, 5.25 - 5.35, 5.47 - 5.725, 5.725 - 5.85 GHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
MIMO	Y
MIMO type	Multi User MIMO
Spread spectrum method	DSSS, OFDM
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Fit AP mode features	Mesh networking
Wi-Fi Multimedia (WMM)/(WME)	Y
VLAN support	Y
Virtual LAN features	Tagged VLAN
Quality of Service (QoS) support	Y
Transmitting power	23 dBmW
Security
Security algorithms	SSH, WPA2-AES, WPA2-Enterprise, WPA2-PSK
MAC address filtering	Y
Service Set Identifier (SSID) features	Multiple SSIDs
Number of SSID supported	8
Protocols
Management protocols	SNMP
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Power
Power over Ethernet (PoE)	Y
Power consumption (max)	12.6 W
Design
Placement	Pole, Wall
Product colour	White
LED indicators	Y
Certification	FCC, CE, IC
Antenna
Antenna type	External
Antenna direction type	Omni-directional
Antenna features	Integrated antenna
Antennas quantity	4
Antenna gain level (max)	5 dBi
Antenna connector type	SMA
Number of connectors	4
Operational conditions
Operating temperature (T-T)	-20 - 60 °C
Storage temperature (T-T)	-40 - 80 °C
Technical details
Harmonized System (HS) code	85176990
Weight & dimensions
Width	111.2 mm
Depth	173.6 mm
Height	30.29 mm
Weight	829.5 g
