EnGenius Cloud Managed Wi-Fi 6 2X2 Access Point ECW210L is a cost-effective model designed for small businesses. It support dual-concurrent 802.11ax architecture, delivering speeds up to 574 Mbps on the 2.4GHz and 2, 400 Mbps on the 5 GHz band, providing high-performance connectivity. With seamless integration into the EnGenius Cloud platform, it offers easy management and robust security through WPA3, making it an ideal solution for businesses seeking enterprise-grade performance at an affordable price.

Specification

Product
Product id	987859
Brand	EnGenius
Partnr	ECW210L
EAN/UPC code	4711488350414
Packaging data
Mounting kit	Y
Features
2.4 GHz	Y
5 GHz	Y
Maximum data transfer rate	2400 Mbit/s
6 GHz	N
Maximum data transfer rate (2.4 GHz)	600 Mbit/s
Maximum data transfer rate (5 GHz)	2400 Mbit/s
Ethernet LAN data rates	10, 100, 1000, 2500 Mbit/s
Frequency band	2.4 - 5.85 GHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Number of users	128 gebruiker(s)
Bluetooth	N
MIMO	Y
MIMO type	Multi User MIMO
Spread spectrum method	DSSS, OFDM, OFDMA
Wi-Fi Multimedia (WMM)/(WME)	Y
Wi-Fi roaming	Y
Fast roaming	Y
Spatial streams	2 x 2
VLAN support	Y
Virtual LAN features	Tagged VLAN
Quality of Service (QoS) support	Y
Maximum Tx power (2.4 GHz)	21 dBmW
Maximum Tx power (5 GHz)	21 dBmW
Security
Security algorithms	WPA2-PSK, WPA3-PSK
MAC address filtering	Y
Service Set Identifier (SSID) features	Hidden SSID
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
DC-in jack	Y
Power
Power over Ethernet (PoE)	Y
DC voltage range	12 V
Input current	1.5 A
Power consumption (max)	10.7 W
Design
Placement	Ceiling, Wall
Product colour	White
Antenna
Antenna type	Internal
Antenna direction type	Omni-directional
Antenna features	Integrated antenna
Antennas quantity	4
Antenna gain level (max)	7 dBi
Performance
Built-in processor	Y
Processor model	ARM Cortex-A53
Processor frequency	1000 MHz
Operational conditions
Operating relative humidity (H-H)	0 - 90 procent
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 80 °C
Storage relative humidity (H-H)	0 - 90 procent
Technical details
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC), UKCA
Weight & dimensions
Width	160 mm
Depth	160 mm
Height	30 mm
Weight	380 g
