EnGenius Cloud Managed Wi-Fi 6 4×4 Indoor Access Point ECW230 S supports dual concurrent 802.11ax Wi-Fi 6 architecture, delivering supercharged speeds up to 2, 400 Mbps (5 GHz), and up to 1, 200 Mbps (2.4 GHz). With WPA3 & WPA2-AES authentication support, remote monitoring & troubleshooting, and Mesh Wireless Support for optimized signal quality, it's easy to set up and manage an unlimited number of APs with the EnGenius Cloud App.

Specification

Product
Product id	987865
Brand	EnGenius
Partnr	ECW230S
EAN/UPC code	4713361935640
Warranty (months)	2 years
Packaging data
Mounting kit	Y
Quick start guide	Y
Package width	245 mm
Package depth	245 mm
Package height	85 mm
Package weight	1134 g
Features
2.4 GHz	Y
5 GHz	Y
Maximum data transfer rate	3548 Mbit/s
6 GHz	N
Maximum data transfer rate (2.4 GHz)	1148 Mbit/s
Maximum data transfer rate (5 GHz)	2400 Mbit/s
Ethernet LAN data rates	10, 100, 1000, 2500 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3at
Bluetooth	Y
Bluetooth version	5.0
MIMO	Y
Bluetooth Low Energy (BLE)	Y
MIMO type	Multi User MIMO
Spread spectrum method	DSSS
Wi-Fi Multimedia (WMM)/(WME)	Y
VLAN support	Y
Virtual LAN features	Tagged VLAN
Dynamic Frequency Selection (DFS)	Y
Quality of Service (QoS) support	Y
BeamForming	Y
Security
Security algorithms	SNMP, SNMPv2, SNMPv3, WPA2-AES, WPA2-Enterprise, WPA3-Enterprise, WPA3-PSK
MAC address filtering	Y
Service Set Identifier (SSID) features	Hidden SSID, Multiple SSIDs
Number of SSID supported	8
Wireless Intrusion Detection System (WIDS)	Y
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
DC-in jack	Y
Power
Power over Ethernet (PoE)	Y
Power consumption (max)	19.5 W
Design
Placement	Ceiling, Wall
Product colour	White
Cable lock slot	Y
Cable lock slot type	Kensington
Reset button	Y
LED indicators	Bluetooth, LAN, Power, WLAN
Certification	CE, FCC
Antenna
Antenna type	Internal
Antenna direction type	Omni-directional
Antenna features	Integrated antenna
Antennas quantity	8
Antenna gain level (max)	6 dBi
Performance
Built-in processor	Y
Processor model	ARM Cortex-A53
Processor frequency	2000 MHz
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 80 °C
Packaging content
Quantity per pack	1 stuk(s)
Weight & dimensions
Width	210 mm
Depth	210 mm
Height	33.2 mm
Weight	607 g
