Delivers Long-Range Point-to-Point Connectivity
When used with another EnStation5 in a Point-to-Point deployment, the devices’ up to 26 dBm transmit power and internal 19 dBi directional high-gain antenna delivers a robust longer range signal to each other — up to 5 miles. Ideal for PtP applications that need to cover large distances where Ethernet or even Fiber cabling is not possible or practical.

Versatile and Reconfigurable Operation Modes
Three (3) operation modes available: Access Point, Client Bridge, or WDS Bridge.

Affordable and Revenue Generating CPE for Wireless Internet Service Providers
Robust and reliable high-performing/very affordable solution for WISPs to offer their community subscriber base and from which to derive recurring revenue. Small form factor makes EnStations an acceptable solution to add to home exteriors for most homeowner associations.

Faster File Transfers and Smoother Video Streaming
Up to 300 Mbps wireless speed.

Prioritizes Applications and Maintains Quality of Experience (IEEE 802.11e)
Intelligent QoS (Quality of Service) prioritizes bandwidth intensive applications like HD video or bandwidth sensitive applications like VoIP telephone calls.

Simplified AP Monitoring and Management
For easier monitoring and maintenance after deployment on rooftops and other hard to reach places, users can monitor the Access Point remotely with SNMP-based EZ Controller wireless Access Point software for Windows, Mac OSX, and Linux.

Specification

Product
Product id	987874
Brand	EnGenius
Partnr	ENSTATION5
EAN/UPC code	4713361934605
Warranty (months)	1 Year
Management features
Web-based management	Y
Firmware upgradeable	Y
Packaging data
Mounting kit	Y
Quick start guide	Y
Package width	247 mm
Package depth	321 mm
Package height	88 mm
Package weight	1040 g
Features
2.4 GHz	N
5 GHz	Y
Maximum data transfer rate	300 Mbit/s
Wi-Fi data rate (max)	300 Mbit/s
Ethernet LAN data rates	10, 100 Mbit/s
Frequency band	5.18 - 5.825 GHz
Networking standards	IEEE 802.11a, IEEE 802.11n, IEEE 802.1x
Channel bandwidth	40 MHz
Automatic channel selection	Y
Modulation	16-QAM, 64-QAM, BPSK, QPSK
VLAN support	Y
Virtual LAN features	Tagged VLAN
Operating modes	Access Point (AP), Client Bridge, Client Router, WDS
Quality of Service (QoS) support	Y
Transmitting power	26 dBmW
Security
Security algorithms	128-bit WEP, 152-bit WEP, 64-bit WEP, WPA, WPA2
MAC address filtering	Y
Number of SSID supported	4
Auto Wireless Distribution System (WDS)	Y
Protocols
DHCP server	Y
Management protocols	SNMP V1/v2c/v3, MIB I/II
Ports & interfaces
Ethernet LAN (RJ-45) ports	2
Power
Power over Ethernet (PoE)	Y
AC input voltage	24 V
Input current	0.6 A
Power consumption (typical)	7 W
Design
Placement	Wall
Product colour	White
International Protection (IP) code	IP55
Reset button	Y
LED indicators	Y
Certification	FCC, CE
Internal	N
Antenna
Antenna direction type	Directional
Antenna features	Integrated antenna
Antennas quantity	1
Antenna gain level (max)	19 dBi
Performance
Internal memory	64 MB
Flash memory	16 MB
Operational conditions
Operating relative humidity (H-H)	0 - 90 procent
Operating temperature (T-T)	-20 - 60 °C
Storage temperature (T-T)	-30 - 80 °C
Storage relative humidity (H-H)	0 - 90 procent
Technical details
Harmonized System (HS) code	85176990
Weight & dimensions
Width	190 mm
Depth	190 mm
Height	38 mm
Weight	460 g
