The EnGenius EOC600 802.11 ax 2x2 5GHz Broadband Outdoor Long Range CPE offers reliable and efficient outdoor Wi-Fi connectivity with EnGenius proprietary MAC and beamforming optimization. It features high 26 dBm transmit power and high gain 16 dBi integrated directional antenna for extended Wi-Fi range up to 3 miles point-to-point. It's also weatherproof and offers flexible operation modes with easy installation over 100 meters.

Specification

Product
Product id	987876
Brand	EnGenius
Partnr	EOC600
EAN/UPC code	4711488350339
Management features
Syslog	Y
Packaging data
Mounting kit	Y
Features
2.4 GHz	N
5 GHz	Y
6 GHz	N
Maximum data transfer rate (5 GHz)	1200 Mbit/s
Frequency band	5.15 - 5.85 GHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11n
Channel bandwidth	160 MHz
MIMO	Y
MIMO type	Multi User MIMO
Spread spectrum method	OFDMA
VLAN support	Y
Virtual LAN features	Tagged VLAN
Maximum Tx power (2.4 GHz)	9 dBmW
Maximum Tx power (5 GHz)	26 dBmW
Security
Security algorithms	256-bit AES
MAC address filtering	Y
IP address filtering	Y
IGMP snooping	Y
Remote Authentication Dial-In User Service (RADIUS)	Y
Protocols
DHCP server	Y
Ports & interfaces
Ethernet LAN (RJ-45) ports	2
Power
Power over Ethernet (PoE)	Y
Power consumption (max)	13 W
Design
Placement	Wall
Product colour	White
International Protection (IP) code	IP55
Antenna
Antenna type	Internal
Antenna direction type	Directional
Antenna features	Integrated antenna
Antennas quantity	2
Antenna gain level (max)	16 dBi
Performance
Internal memory	512 MB
Flash memory	128 MB
Operational conditions
Operating relative humidity (H-H)	0 - 90 procent
Operating temperature (T-T)	-20 - 60 °C
Storage temperature (T-T)	-40 - 80 °C
Storage relative humidity (H-H)	0 - 90 procent
Technical details
Compliance certificates	CB, CE, Federal Communications Commission (FCC), Industry Canada (IC), RoHS, UKCA, WEEE
Packaging content
Quantity per pack	1 stuk(s)
Weight & dimensions
Width	260 mm
Depth	84 mm
Height	55 mm
Weight	610 g
