EnGenius SFP3213-10A SFP plus Transceivers are hot-swappable multi-purpose optical modules support 10Gigabit Ethernet applications across most switching and routing platforms. The transceivers support to operate at 10Gbps serial optical data transfer rates on a single duplex fiber core with a length of up to 10, 000m, ideally suited for data centers, enterprise and storage area networks.

Specification

Product
Product id	987917
Brand	EnGenius
Partnr	SFP2313-20A
EAN/UPC code	4713361935800
Network
SFP transceiver type	Fiber optic
Technical details
Compliance certificates	RoHS
Performance
Maximum data transfer rate	10312.5 Mbit/s
Interface type	SFP+
Single-mode fiber (SMF) supported	Y
Fiber optic connector	LC
Maximum transfer distance	10000 m
Wavelength	1310 nm
Ethernet LAN	Y
Ethernet interface type	10 Gigabit Ethernet
Networking standards	IEEE 802.3az, IEEE 802.3ae
Features
Product colour	Grey
Hot-swap	Y
Power
Input voltage	3.13 - 3.46 V
Maximum voltage	3.46 V
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	5 - 95 procent
Weight & dimensions
Width	13.9 mm
Depth	58.4 mm
Height	12.6 mm
Weight	25 g
