OPTIMIZED PERFORMANCE AND DENSITY
Ideal dual-socket platform for dense scale-out data center computing powered by latest 4th Generation Intel® Xeon® Scalable Processors with up to 60 cores per CPU.

POWER YOUR APPLICATIONS
Combine performance and versatility to adapt to a variety of applications and meet future demands with 32 DIMM modules and up to 8 TB of memory. DDR5 DIMM memory provides fast, high capacity for memory intensive workloads.

EASY EXPANDABILITY
Benefit from the flexibility of 2.5”, 3.5” storage devices for highest capacities with up to 10 drives per height unit (U) and additional expandability with up to 3 PCIe 5.0 /1x PCIe 4.0 (for Internal RAID controller) slots flexible adapters via OCP v3.

COMPREHENSIVE PROTECTION
Benefit from advanced security technologies such as Platform Firmware Resilience (PFR) to protect the most sensitive portions of a workload, encryption support to enhance data and VM protection as well as physical protection to avoid unauthorized access.

Specification

Product
Product id	968055
Brand	Fujitsu Technology Solutions
Partnr	VFYR2537SC540IN
EAN/UPC code	4066733144264
Processor
Processor manufacturer	Intel
Processor family	Intel Xeon Silver
Processor model	4509Y
Processor frequency	2.6 GHz
Processor boost frequency	4.1 GHz
Processor cores	8
Processor cache	22.5 MB
Motherboard chipset	Intel C741
Memory
Internal memory	32 GB
Internal memory type	DDR5-SDRAM
ECC	Y
Memory clock speed	4800 MHz
Maximum internal memory	8000 GB
Storage
HDD size	2.5
Number of HDDs supported	8
RAID support	Y
Network
Ethernet LAN	Y
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
VGA (D-Sub) ports quantity	1
Expansion slots
PCI Express x16 (Gen 4. x) slots	1
Design
Chassis type	Rack (1U)
Product colour	Black
Redundant fans support	Y
Performance
Trusted Platform Module (TPM) version	2.0
Trusted Platform Module (TPM)	Y
Software
Operating system installed	N
Compatible operating systems	Windows Server 2022 Datacenter Windows Server 2022 Standard Windows Server 2019 Datacenter Windows Server 2019 Standard Windows Server 2019 Essentials SUSE® Linux Enterprise Server 15 Red Hat® Enterprise Linux 8
Power
Redundant power supply (RPS) support	Y
Power supply	900 W
Number of redundant power supplies installed	1
Power supply input voltage	100 - 240
Power supply input frequency	50/60 Hz
Weight & dimensions
Width	482.2 mm
Depth	807.45 mm
Height	42.7 mm
Weight	18200 g
