Where Compute Reigns
3rd Gen Intel® Xeon® Scalable Processors – “Ice Lake”
GIGABYTE servers and Intel Xeon Scalable Processors deliver incredible 1P/2P performance from edge to data center with incredible gains in I/O throughput and workload demands that need high performing CPUs with large, yet optimized, memory configurations.

Enhanced I/0: Support for PCIe 4.0 allows for double the throughput of PCIe 3.0 for fast and large data transfers. Also, 64 lanes per socket with up to 128 lanes in a 2P configuration for fast data transmission from CPU to GPU, accelerator or storage.
CPU Performance Boost: Now up to 40 cores per socket with greatly improved IPC on Intel’s 10nm architecture while operating CPUs at 105-270W. Also, an additional UPI lane is added for up to 11.2GT/s for a low latency interconnect between CPUs.
Next Gen Memory: Each processor provides eight memory channels to support 8 or 16 DIMM slots with up to DDR4-3200. There are two sub-clustering modes, Sub NUMA (SNC) and Hemisphere (HEMI), available using balanced memory that results in performance improvements. Additionally, support for Intel Optane PMem 200 series provides two modes for greater memory capacity and data persistence to process large amounts of data faster.
Next Level Security: New instructions and architecture deliver a high level of cryptographic operations for data privacy and protection. Cryptographic accelerators speed up encryption protocols as well as improvements in software guard extensions and memory encryption are added.
AI Acceleration: AI inference and training are enhanced with DL Boost Technology for greater business, operational, and security insights. Applications include HPC, AI, and Media & Graphics.

Specification

Product
Product id	810225
Brand	Gigabyte
Partnr	6NR182340MR-00
EAN/UPC code	4719331600174
Processor
Built-in processor	N
Motherboard chipset	Intel C621A
Processor socket	LGA 4189
Processor manufacturer	Intel
Processor family	Intel Xeon
Number of processors supported	2
Memory
Number of DIMM slots	32
Supported memory types	DDR4-SDRAM
Supported DIMM module capacities	16GB, 32GB, 64GB, 128GB
Supported RDIMM clock speeds	2933, 3200 MHz
Memory channels	Octa-channel
Storage
Number of storage drives supported	4
Hot-swap HDD bays	Y
Number of 2.5" bays	10
Graphics
On-board graphics adapter model	Aspeed AST2500
Discrete graphics adapter model	Not available
Network
Ethernet LAN	Y
Ethernet interface type	Gigabit Ethernet
Ethernet LAN data rates	10, 100, 1000 Mbit/s
LAN controller	Intel I350-AM2
Ports & interfaces
Ethernet LAN (RJ-45) ports	2
VGA (D-Sub) ports quantity	1
COM ports quantity	1
Expansion slots
PCI Express slots version	4.0
PCI Express x16 slots	4
Number of M.2 (M) slots	1
Features
Trusted Platform Module (TPM)	Y
Trusted Platform Module (TPM) version	2.0
Backplanes support	Y
Harmonized System (HS) code	84714100
Compatible operating systems	Windows Server 2016 ( X2APIC/256T not supported) Windows Server 2019 Red Hat Enterprise Linux 8.3 ( x64) or later SUSE Linux Enterprise Server 12 SP5 ( x64) or later SUSE Linux Enterprise Server 15 SP2 ( x64) or later Ubuntu 18.04.5 LTS (x64) or later Ubuntu 20.04 LTS (x64) or later VMware ESXi 6.7 Update3 P03 or later VMware ESXi 7.0 Update1 or later Citrix Hypervisor 8.2.0 or later
Design
Chassis type	Rack (1U)
LED indicators	HDD, LAN, Status
Power
Power supply	1200 W
Number of main power supplies	2
AC input voltage	100 - 240 V
DC output current (+12 V)	97 A
Operational conditions
Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	8 - 80 procent
Storage relative humidity (H-H)	20 - 95 procent
Weight & dimensions
Width	438 mm
Depth	43.5 mm
Height	730 mm
Weight	13000 g
Packaging data
Packaging content	1 x R182-Z93 2 x CPU heatsinks 1 x Rail kit
Package width	985 mm
Package depth	588 mm
Package height	250 mm
Package weight	22000 g
