Extremely fast PCIe 4.0 throughput
AORUS Gen4 7300 SSD delivers sequential read up to 7.3GB/s with 8 Channel controller- Phison E18- and 3D TLC NAND. The E18 controller is built with the advanced 12nm process ensuring sufficient computing power. Also it supports up to 8 NAND Flash channel with 32CE, DDR4 SLC caching and meets NVMe 1.4.

NAND Flash Selected for High Quality and Performance
Selected High Speed 3D TLC NAND Flash (1600+ MT/s)
The ultra high speed 3D TLC NAND Flash is operating at 1600+ MT/s, which is 50% more than the prevision version that leads to better performance.

Xtreme Storage Performance
By adopting Phison E18 controller and 3D TLC NAND, AORUS Gen4 7300 SSD delivers blazing speeds: up to 7, 300 MB/s for sequential read, and up to 6, 000MB/s sequential write. Sequential Read performance of PCIe 4.0 SSDs is 2 times faster than the PCIe 3.0 SSDs. Get ready to enter the next generation of computing with faster and smoother, gaming, streaming, and graphics intensive rendering.

GIGABYTE CONTROL CENTER (GCC)
GIGABYTE CONTROL CENTER (GCC) is a unified software for all GIGABYTE supported products. It provides newly designed intuitive user interface to control all essential function.
- Unified software platform for all Gigabyte supported products
- Intuitive user interface for an eased experience
- Modularized control components only for installed hardware
- Auto update function to keep system up to date and support future products

Specification

Product
Product id	1010106
Brand	Gigabyte
Partnr	AG4731TB N
EAN/UPC code	4719331869700
Warranty (months)	5 years limited
Features
SSD form factor	M.2
SSD capacity	1000 GB
Interface	PCI Express 4.0
Memory type	3D TLC NAND
NVMe	Y
NVMe version	1.4
Component for	PC/Notebook
Hardware encryption	Y
Security algorithms	256-bit AES
Read speed	7300 MB/s
Write speed	6000 MB/s
PCI Express interface data lanes	x4
M.2 SSD size	2280 (22 x 80 mm)
TRIM support	Y
S. M. A. R. T. support	Y
Mean time between failures (MTBF)	1600000 uur
External DDR cache	Y
External DDR cache quantity	1024 MB
Windows operating systems supported	Windows 10 x64, Windows 11 x64
TBW rating	700
Power
Power consumption (read)	6.6 W
Power consumption (write)	6.7 W
Power consumption (idle)	0.03 W
Brand-specific features
Brand specific technologies	SLC Caching
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	-40 - 85 °C
Weight & dimensions
Width	22 mm
Depth	80 mm
Height	2.3 mm
Packaging data
Manual	Y
Package type	Box
