Lenovo ThinkCentre M90a Pro Gen 6. Product type: All-in-One PC. Display diagonal: 68.6 cm (27"), HD type: Quad HD, Display resolution: 2560 x 1440 pixels, Panel type: IPS. Processor family: Intel Core Ultra 5. Internal memory: 16 GB, Internal memory type: DDR5-SDRAM. Total storage capacity: 512 GB, Storage media: SSD. On-board graphics card model: Intel® Graphics. Built-in camera. Operating system installed: Windows 11 Pro. Product colour: Black

Specification

Product
Product id	1020956
Brand	Lenovo
Partnr	13AM0007MH
EAN/UPC code	198157090187
Display
Display diagonal	27 inch
Display resolution	2560 x 1440 Pixels
Touchscreen	N
HD type	Quad HD
Native aspect ratio	16:9
Display brightness	400 cd/m²
Panel type	IPS
Anti-glare screen	Y
RGB colour space	sRGB
Colour gamut	99 procent
Processor
Processor manufacturer	Intel
Processor family	Intel Core Ultra 5
Processor model	235
Processor generation	Intel Core Ultra (Series 2)
Processor boost frequency	5 GHz
Efficient-core base frequency	2.9 GHz
Processor cores	14
Processor threads	14
Processor cache	24 MB
Processor cache type	Smart Cache
Performance-core base frequency	3.4 GHz
Efficient-core Max Turbo Frequency	4.4 GHz
Performance-core Max Turbo Frequency	5 GHz
Motherboard chipset	Intel Q870
Performance cores	6
Efficient cores	8
Processor base power	65 W
Maximum turbo power	121 W
Memory
Internal memory	16 GB
Internal memory type	DDR5-SDRAM
Maximum internal memory	64 GB
Memory slots	2
Memory slots type	SO-DIMM
Memory clock speed	5600 MHz
Memory layout (slots x size)	1 x 16 GB
Memory form factor	DIMM/SO-DIMM
Neural processor unit (NPU)
Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Y
Windows Studio effects support	Y
AI software frameworks supported by NPU	DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance (up to)	27 TOPs
NPU performance up to	13 TOPs
GPU performance up to	6 TOPs
Storage
Total storage capacity	512 GB
Storage media	SSD
Total SSDs capacity	512 GB
Number of SSDs installed	1
SSD capacity	512 GB
SSD interface	PCI Express 4.0
SSD form factor	M.2
NVMe	Y
Optical drive type	N
Card reader integrated	Y
Graphics
Discrete graphics adapter	N
Discrete graphics adapter model	Not available
On-board graphics adapter	Y
On-board graphics adapter family	Intel Graphics
On-board GPU manufacturer	Intel
On-board graphics adapter model	Intel Graphics
Audio
Built-in speaker(s)	Y
Number of speakers	2
RMS rated power	10 W
Built-in microphone	Y
Camera
Built-in camera	Y
Total megapixels	5 MP
Privacy camera	Y
Privacy type	Privacy shutter
Network
Wi-Fi	Y
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN controller manufacturer	Intel
Wi-Fi standards	Wi-Fi 6E (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX211
Antenna type	2x2
Ethernet LAN	Y
Ethernet LAN data rates	100, 1000 Mbit/s
Bluetooth	Y
Bluetooth version	5.3
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Intel® Thunderbolt 4	Y
HDMI ports quantity	1
Thunderbolt 4 ports quantity	1
DisplayPorts quantity	1
Combo headphone/mic port	Y
USB Sleep-and-Charge	Y
Design
Product colour	Black
Cable lock slot	Y
Cable lock slot type	Kensington
Performance
Product type	All-in-One PC
Trusted Platform Module (TPM)	Y
Trusted Platform Module (TPM) version	2.0
Software
Operating system installed	Windows 11 Pro
Operating system language	ENG, FRE, DEU, DUT, ITA
Power
AC adapter power	180 W
Weight & dimensions
Width (with stand)	613.6 mm
Depth (with stand)	222.21 mm
Weight (with stand)	12310 g
Packaging content
Mouse included	Y
Mouse connectivity	Wireless
Keyboard included	Y
Keyboard language	English
Keyboard connectivity	Wireless
