LENOVO THINKSTATION P3 ULTRA SFF GEN 2
Redefining the Power of Small

Experience extraordinary performance in an intelligently compact design. Powered by Intel® Core™ Ultra (Series 2) processors with Intel vPro®, with integrated NPU and NVIDIA RTX™ graphics, this workstation breaks new ground by delivering AI-optimized performance and ultimate flexibility in a chassis less than 4L in total volume.

POWERFUL COMBINED AI ACCELERATION
Experience AI-Enhanced Productivity, Creativity & Security

The ThinkStation P3 Ultra SFF Gen 2 workstation combines an integrated Intel® NPU with NVIDIA RTX™ 4000 SFF Ada Generation graphics for unparalleled AI inferencing — totalling up to 335 TOPS of AI horsepower with the CPU and GPU. Handle everything from deep learning models to real-time analytics without sacrificing space or energy efficiency.

CREDIBILITY & COLLABORATION
Sustainability

Our goal is to provide smarter technology that builds a brighter, more sustainable future for our customers, communities, and the planet. That's why we pursue industry leading labels and certifications that demonstrate our commitment to sustainability in product design. Together, we can build a smarter future for all.

Specifications may vary depending upon region / model.

Specification

Product
Product id	1002959
Brand	Lenovo
Partnr	30J50063BF
EAN/UPC code	199272558040
Warranty (months)	3-year, Onsite; 1Y Premier Support from 3Y Onsite Windchill bundles (CPN)
Processor
Processor manufacturer	Intel
Processor family	Intel Core Ultra 9
Processor generation	Intel Core Ultra (Series 2)
Processor model	285
Processor cores	24
Processor boost frequency	5.6 GHz
Performance cores	8
Efficient cores	16
Processor cache	36 MB
Processor cache type	Smart Cache
Performance-core base frequency	2.5 GHz
Processor threads	24
Efficient-core base frequency	1.9 GHz
Efficient-core Max Turbo Frequency	4.6 GHz
Performance-core Max Turbo Frequency	5.4 GHz
Number of processors installed	1
Processor base power	65 W
Maximum turbo power	182 W
Memory
Internal memory	64 GB
Internal memory type	DDR5-SDRAM
Maximum internal memory	128 GB
Memory layout (slots x size)	2 x 32 GB
Memory slots	2x SO-DIMM
Memory clock speed	5600 MHz
Memory channels	Dual-channel
Non-ECC	Y
Neural processor unit (NPU)
Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Y
Windows Studio effects support	Y
AI software frameworks supported by NPU	DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance (up to)	36 TOPs
NPU performance up to	13 TOPs
GPU performance up to	8 TOPs
Storage
Total storage capacity	1000 GB
Optical drive type	N
Storage media	SSD
Total SSDs capacity	1000 GB
Number of SSDs installed	1
SSD capacity	1000 GB
SSD interface	PCI Express 4.0
NVMe	Y
SSD form factor	M.2
M.2 SSD size	2280 (22 x 80 mm)
Graphics
Discrete graphics adapter	Y
On-board graphics adapter	Y
Discrete GPU manufacturer	NVIDIA
Discrete graphics adapter model	NVIDIA RTX 4000 Ada
Discrete graphics memory type	GDDR6
Discrete graphics adapter memory	20 GB
Number of discrete graphics adapters	1
On-board graphics adapter family	Intel Graphics
On-board GPU manufacturer	Intel
On-board graphics adapter model	Intel Graphics
Graphics card Mini DisplayPort ports quantity	4
Network
Ethernet LAN	Y
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Wi-Fi	Y
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi standards	Wi-Fi 7 (802.11be)
WLAN controller model	Intel Wi-Fi 7 BE200
Antenna type	2x2
Bluetooth	Y
Bluetooth version	5.4
Ports & interfaces
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	5
USB 3.2 Gen 2x2 Type-C ports quantity	2
DisplayPorts quantity	3
DisplayPort version	1.2
Ethernet LAN (RJ-45) ports	1
Combo headphone/mic port	Y
Design
Chassis type	Mini Tower
Volume	3.9 l
Placement supported	Vertical
Cable lock slot	Y
Cable lock slot type	Kensington
Product colour	Black
Performance
Product type	Workstation
Motherboard chipset	Intel W880
Audio chip	Realtek ALC623-CG
Audio system	High Definition Audio
Built-in speaker(s)	Y
Number of speakers	1
Password protection	Y
Password protection type	BIOS, Power on
Trusted Platform Module (TPM)	Y
Software
Operating system installed	Windows 11 Pro
Operating system language	DEU, DUT, ENG, FRE, ITA
Bundled software	Lenovo AI Now
Power
Power supply	330 W
Power supply input voltage	100 - 240
Power supply input frequency	50/60 Hz
Operational conditions
Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	20 - 80 procent
Storage relative humidity (H-H)	10 - 90 procent
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 12192 m
Certificates
Certification	RoHS compliant TCO Certified, generation 10
Weight & dimensions
Width	87 mm
Depth	223 mm
Height	202 mm
Weight	3600 g
Packaging content
Display included	N
Mouse connectivity	Wired
Mouse included	Y
Keyboard included	N
