Intel® Optane™ Memory Supported
Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration.

Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.

Intel® vPro™ Platform Eligibility
Intel® vPro™ Technology is a set of security and manageability capabilities built into the processor aimed at addressing four critical areas of IT security: 1) Threat management, including protection from rootkits, viruses, and malware 2) Identity and web site access point protection 3) Confidential personal and business data protection 4) Remote and local monitoring, remediation, and repair of PCs and workstations.

Specification

Product
Product id	888898
Brand	Intel
Partnr	CM8068403380018
EAN/UPC code	8592978109776
Warranty (months)	12 months
Processor
Processor manufacturer	Intel
Processor family	Intel Xeon E
Processor model	E-2176G
Processor codename	Coffee Lake
Box	N
Cooler included	N
Component for	Server/Workstation
Processor socket	LGA 1151 (Socket H4)
Processor cores	6
Processor threads	12
Processor base frequency	3.7 GHz
Processor boost frequency	4.7 GHz
Thermal Design Power (TDP)	80 W
Processor lithography	14 nm
System bus rate	8 GT/s
Processor operating modes	64-bit
Processor cache	12 MB
Processor cache type	Smart Cache
Stepping	U0
Bus type	DMI3
Memory bandwidth supported by processor (max)	41.6 GB/s
Processor code	SR3WS
Processor ARK ID	134860
Memory
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2666 MHz
Memory channels	Dual-channel
ECC	Y
Graphics
On-board graphics adapter	Y
Discrete graphics adapter	N
On-board graphics adapter model	Intel UHD Graphics P630
Maximum on-board graphics adapter memory	128 GB
On-board graphics adapter outputs supported	Embedded DisplayPort (eDP), DisplayPort, HDMI, DVI
On-board graphics adapter dynamic frequency (max)	1200 MHz
On-board graphics adapter base frequency	350 MHz
Number of displays supported (on-board graphics)	3
On-board graphics adapter 4K support	Y
On-board graphics adapter OpenGL version	4.5
On-board graphics adapter DirectX version	12.0
On-board graphics adapter maximum resolution (DisplayPort)	4096 x 2304 Pixels
On-board graphics adapter maximum resolution (HDMI)	4096 x 2160 Pixels
On-board graphics adapter maximum resolution (eDP - Integrated Flat Panel)	4096 x 2304 Pixels
On-board graphics adapter refresh rate at maximum resolution (HDMI)	24 Hz
On-board graphics adapter refresh rate at maximum resolution (eDP - Integrated Flat Panel)	60 Hz
On-board graphics adapter refresh rate at maximum resolution (DisplayPort)	60 Hz
On-board graphics adapter ID	0x3E96
Discrete graphics adapter model	Not available
Features
Execute Disable Bit	Y
Idle States	Y
Thermal Monitoring Technologies	Y
Maximum number of PCI Express lanes	16
PCI Express slots version	3.0
PCI Express configurations	1x16, 2x8, 1x8+2x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
PCI Express CEM revision	3.0
Scalability	1S
CPU configuration (max)	1
Embedded options available	Y
Market segment	Server
Harmonized System (HS) code	85423119
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G077159
Processor special features
Intel® AES New Instructions (Intel® AES-NI)	Y
Enhanced Intel SpeedStep Technology	Y
Intel Trusted Execution Technology	Y
Intel® Memory Protection Extensions (Intel® MPX)	Y
Intel® Clear Video HD Technology (Intel® CVT HD)	Y
Intel® Hyper Threading Technology (Intel® HT Technology)	Y
Intel® Turbo Boost Technology	2.0
Intel® Quick Sync Video Technology	Y
Intel® InTru™ 3D Technology	Y
Intel® Turbo Boost Technology 2.0 frequency	4.7 GHz
Intel® Transactional Synchronization Extensions	Y
Intel® Optane™ Memory Ready	Y
Intel® Boot Guard	Y
Intel® vPro™ Platform Eligibility	Y
Intel TSX-NI version	1.00
Intel® OS Guard	Y
Intel TSX-NI	Y
Intel® Secure Key	Y
Intel VT-x with Extended Page Tables (EPT)	Y
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Y
Intel Enhanced Halt State	Y
Intel Clear Video Technology	Y
Intel Virtualization Technology (VT-x)	Y
Intel Virtualization Technology for Directed I/O (VT-d)	Y
Intel Secure Key Technology version	1.00
Intel 64	Y
Intel Software Guard Extensions (Intel SGX)	Y
Operational conditions
Tjunction	100 °C
Packaging data
Package width	70 mm
Package depth	116 mm
Package height	101 mm
Package weight	316.1 g
Package type	Retail box
Technical details
Supported memory types	DDR4-SDRAM
Maximum graphics adapter memory	128 GB
Product type	Processor
Processor cache	12288 KB
Last change	63903513
Processor ID	0x3E96
Bus speed	8 GT/s
Product family	Intel Xeon Processors
Processor brand name	Intel Xeon
Bus bandwidth	8
Bus type units	GT/s
Launch date	Q3'18
Maximum resolution & refresh rate (DisplayPort)	4096x2304@60Hz
Maximum resolution & refresh rate (HDMI)	4096x2160@24Hz
Maximum resolution & refresh rate (Integrated Flat Panel)	4096x2304@60Hz
Maximum resolution & refresh rate (VGA)	N/A
Status	Launched
Maximum memory	128 GB
Servicing status	Baseline Servicing
Weight & dimensions
Processor package size	37.5 x 37.5 mm
Other features
Maximum internal memory	128 GB
Maximum internal memory	65536 MB
Video decoding	Y
Graphics output	eDP/DP/HDMI/DVI
