Intel® Data Direct I/O Technology is a platform technology that improves I/O data processing efficiency for data delivery and data consumption from I/O devices. With Intel DDIO, Intel® Server Adapters and controllers talk directly to the processor cache without a detour via system memory, reducing latency, increasing system I/O bandwidth, and reducing power consumption.

Intel® Ethernet Power Management Technology provides solutions to common power management approaches by reducing idle power, reducing capacity and power as a function of demand, operating at maximum energy efficiency whenever possible, and enabling functionality only when needed.

Single-Root I/O Virtualization (SR-IOV) involves natively (directly) sharing a single I/O resource between multiple virtual machines. SR-IOV provides a mechanism by which a Single Root Function (for example a single Ethernet Port) can appear to be multiple separate physical devices.

Specification

Product
Product id	551192
Brand	Intel
Partnr	X710T4
EAN/UPC code	5032037086813
Warranty (months)	36 months
Ports & interfaces
Connectivity technology	Wired
Host interface	PCI Express
Interface	Ethernet
Ethernet LAN	Y
Ethernet LAN (RJ-45) ports	4
PCI version	3.0
Network
Maximum data transfer rate	10000 Mbit/s
Networking standards	IEEE 802.1Q, IEEE 802.1as, IEEE 802.1p, IEEE 802.3, IEEE 802.3ad
Ethernet interface type	10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet LAN data rates	100, 1000, 10000 Mbit/s
Cabling technology	10GBase-T
iSCSI support	Y
VLAN tagging	Y
Maximum operating distance	100 m
LAN controller	Intel XL710
Design
Internal	Y
Product colour	Black, Green
PCI Card form factor	Half-height (low-profile)
Operational conditions
Operating temperature (T-T)	0 - 55 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	0 - 90 procent
System requirements
Compatible operating systems	https://www. intel. com/content/www/us/en/support/articles/000025890/network-and-i-o/ethernet-products. html
Linux operating systems supported	Y
Server operating systems supported	Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2012 R2, Windows Server 2012 R2 x64
Other features
Data transfer rate	8 GT/s
Cable type	RJ45 Category 6 up to 55m; Category 6A up to 100m
Intel Data Direct I/O Technology	Y
Intel Virtualization Technology for Connectivity (VT-c)	Y
Interface type	PCIe v3.0 (8.0GT/s)
Market segment	LAD
Product type	Network Interface Card
Cabling type	RJ45 Category 6 up to 55m; Category 6A up to 100m
Controller type	Intel® Ethernet Controller XL710
Commodity Classification Automated Tracking System (CCATS)	NA
Export Control Classification Number (ECCN)	5A991
Harmonized System (HS) code	8517620090
Ethernet adapter ARK ID	93428
Processor family	700 Network Adapters (up to 40GbE)-700 Network Adapters (up to 40GbE)
Bracket height	Low-Profile (LP) / Full-Height (FH)
Number of VLANs	4096
PCI-SIG* SR-IOV Capable	Y
Intel Virtual Machine Device Queues (VMDq)	Y
On-chip QoS and Traffic Management	Y
Intel Flexible Port Partitioning	Y
Speed & slot width	8.0 GT/s, x8 Lane
iWARP/RDMA	N
Intelligent Offloads	Y
Low halogen options available	N
Target market	Artificial Intelligence, High Performance Computing
Status	Launched
Product brief URL	http://www. intel. com/content/www/us/en/ethernet-products/converged-network-adapters/ethernet-x710-t4-brief. html
Network interface card type	Server
Network interface card cable medium	Copper
Launch date	Q4'16
Last change	64826840
Storage Over Ethernet	iSCSI, NFS
Product family	Intel 10 Gigabit server adapter
Product series	700 Series Network Adapters (up to 40GbE)
