This compact multi-port adapter is ideal for travel, featuring everything from the essential HDMI™ output, USB™ ports to Gigabit Ethernet and 86W Power Delivery passthrough. It gives you the ability to connect your Chromebook™, MacBook®, or other USB-C® compatible laptops to a 4K monitor or TV with 60 Hz refresh rate and audio. With USB™ Power Delivery 3.0, you can charge your laptop and power your peripherals with a single USB-C® power adapter even if your laptop only has one USB-C® port. In addition, you can connect or charge your USB™ devices via the SuperSpeed USB™ 5Gbps ports and access a wired network through the Gigabit Ethernet port.

Through a single USB-C® (Thunderbolt™ 3 compatible) host cable, this compact adapter provides all the essential connectivity you need to create a workstation virtually anywhere!

Specification

Product
Product id	990344
Brand	j5create
Partnr	JCD391-N
EAN/UPC code	4712795086379
Warranty (months)	2 year manufacturer warranty
Ports & interfaces
Connectivity technology	Wired
Host interface	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
USB Power Delivery	Y
USB Power Delivery revision	3.0
USB Power Delivery up to	85 W
HDMI ports quantity	1
Microphone in	N
USB Type-C DisplayPort Alternate Mode	Y
Network
Ethernet LAN	Y
Ethernet LAN (RJ-45) ports	1
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Performance
Product colour	Silver
Card reader integrated	N
Data transfer rate	5 Gbit/s
Number of displays supported	1
Maximum refresh rate	60 Hz
Compatibility	Available USB-C® port that supports DisplayPort™ alternate mode and USB™ Power Delivery 2.0 or 3.0.
Display modes	Extended, Mirror, Primary display
Housing material	Aluminium
Plug and Play	Y
Country of origin	Taiwan
Certification	Works with Chromebook
Power
Output current	0.4 A
Output voltage	20 V
Power consumption (typical)	2 W
USB cable length	0.2 m
Software
Windows operating systems supported	Y
Mac operating systems supported	Y
Other operating systems supported	ChromeOS
Weight & dimensions
Width	66.5 mm
Depth	14.7 mm
Height	77.6 mm
Weight	74.8 g
Packaging data
Quantity per pack	1 stuk(s)
Package width	155 mm
Package depth	95 mm
Package height	30.8 mm
Package weight	129 g
Packaging content
Manual	Y
Quick start guide	Y
Cables included	USB Type-C
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-17 - 68 °C
Operating relative humidity (H-H)	0 - 85 procent
Storage relative humidity (H-H)	0 - 85 procent
Technical details
Master (outer) case GTIN (EAN/UPC)	24712795086373
Warranty period	2 jaar
Logistics data
Quantity per shipping (inner) case	6 stuk(s)
Export Control Classification Number (ECCN)	EAR99
Master (outer) case weight	3880 g
Master (outer) case height	190 mm
Master (outer) case length	435 mm
Master (outer) case width	230 mm
Quantity per master (outer) case	24 stuk(s)
Shipping (inner) case width	103 mm
Shipping (inner) case length	218 mm
Shipping (inner) case height	165 mm
Shipping (inner) case net weight	870 g
Other features
Special features	Chromebook™ Certified, 5-in-1 Functions, 86W of Pass-Through Charging
