Product |
Product id
| 973646
|
Brand
| Kyocera
|
Partnr
| 1102Z13NL0
|
EAN/UPC code
| 632983071779
|
Warranty (months)
| 1-year warranty as standard. ** KYOCERA guarantees the drum and developer for 3 years or 300, 000 pages (whichever occurs sooner), provided each device is used and cleaned in accordance with the service instructions.
|
Print technology |
Replacement cartridges
| TK-5390K, TK-5390C, TK-5390M, TK-5390Y
|
Processor |
Built-in processor
| Y
|
Packaging data |
Package width
| 702 mm
|
Package depth
| 567 mm
|
Package height
| 617 mm
|
Package weight
| 41000 g
|
Certificates |
Waste Electrical and Electronic Equipment (WEEE) compliance
| Y
|
Printing |
Colour
| Y
|
Print technology
| Laser
|
Duplex printing
| Y
|
Duplex printing mode
| Auto
|
Maximum resolution
| 1200 x 1200 pixels
|
Print speed (black, normal quality, A4/US Letter)
| 45 ppm
|
Print speed (colour, normal quality, A4/US Letter)
| 45 ppm
|
Duplex print speed (black, normal quality, A4/US Letter)
| 37 ppm
|
Duplex print speed (colour, normal quality, A4/US Letter)
| 37 ppm
|
Warm-up time
| 20 s
|
Time to first page (black, normal)
| 5.1 s
|
Time to first page (colour, normal)
| 6.2 s
|
Economical printing
| Y
|
Features |
Maximum duty cycle
| 100000 pagina's per maand
|
Recommended duty cycle
| 1500 - 5000 pagina's per maand
|
Printing colours
| Black, Cyan, Magenta, Yellow
|
Number of print cartridges
| 4
|
Page description languages
| JPEG, OpenXPS, PCL 5c, PCL 6, PCL XL, PCLm, PDF, PWG, TIFF, URF, XPS
|
Printer fonts
| Barcode, Bitmap, PCL
|
Introduction month
| October
|
Introduction year
| 2023
|
Input & output capacity |
Total number of input trays
| 2
|
Total input capacity
| 650 vel
|
Total output capacity
| 500 vel
|
Paper tray 1 input capacity
| 550 vel
|
Multi-Purpose tray
| Y
|
Multi-Purpose tray input capacity
| 100 vel
|
Maximum number of input trays
| 6
|
Maximum input capacity
| 2850 vel
|
Maximum output capacity
| 500 vel
|
Paper handling |
Maximum ISO A-series paper size
| A4
|
Maximum print size
| 216 x 356 mm
|
Paper tray media types
| Letterhead, Plain paper, Pre-Printed, Thicker paper
|
ISO A-series sizes (A0. . . A9)
| A4, A5, A6
|
ISO B-series sizes (B0. . . B9)
| B5, B6
|
Non-ISO print media sizes
| Legal (media size), Letter (media size)
|
Custom media width
| 105 - 216 mm
|
Custom media length
| 140 - 356 mm
|
Paper tray media weight
| 60 - 220 g/m²
|
Ports & interfaces |
Direct printing
| Y
|
USB port
| Y
|
USB 2.0 ports quantity
| 3
|
Network |
Wi-Fi
| N
|
Ethernet LAN
| Y
|
Ethernet LAN data rates
| 10, 100, 1000 Mbit/s
|
Cabling technology
| 10/100/1000Base-T(X)
|
Bluetooth
| N
|
Near Field Communication (NFC)
| N
|
Security algorithms
| SNMPv3, TLS
|
Mobile printing technologies
| Apple AirPrint, Kyocera Mobile Print, Mopria Print Service
|
Performance |
Internal memory
| 1000 MB
|
Maximum internal memory
| 3000 MB
|
Memory slots
| 1
|
Storage media
| SSD
|
Card reader integrated
| N
|
Sound pressure level (printing)
| 54 dB
|
Sound pressure level (duplex printing)
| 54 dB
|
Sound pressure level (quiet mode)
| 50 dB
|
Sound power level (standby)
| 30 dB
|
Design |
Market positioning
| Business
|
Product colour
| Black, White
|
Built-in display
| Y
|
Display
| LCD
|
Colour display
| N
|
Touchscreen
| N
|
Display number of lines
| 5 regels
|
Control type
| Buttons
|
Country of origin
| Vietnam
|
Technical details |
Sustainability certificates
| EPEAT Gold, Eco Mark Program
|
Compliance certificates
| CE, REACH, RoHS, cTUVus, UKCA, WEEE
|
Compatible memory cards
| SD
|
Supplier features |
Product or Article Information Sheet available?
| Y
|
Power |
Power consumption (printing)
| 576.8 W
|
Power consumption (max)
| 1289 W
|
Power consumption (ready)
| 11.8 W
|
Power consumption (PowerSave)
| 0.4 W
|
Power consumption (off)
| 0.1 W
|
Energy Star Typical Electricity Consumption (TEC)
| 0.43 kWh/week
|
AC input voltage
| 220 - 240 V
|
AC input frequency
| 50/60 Hz
|
System requirements |
Windows operating systems supported
| Y
|
Mac operating systems supported
| Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
|
Linux operating systems supported
| Y
|
Other operating systems supported
| ChromeOS
|
Operational conditions |
Operating temperature (T-T)
| 10 - 32.5 °C
|
Storage temperature (T-T)
| -20 - 40 °C
|
Operating relative humidity (H-H)
| 10 - 80 procent
|
Storage relative humidity (H-H)
| 10 - 90 procent
|
Operating altitude
| 0 - 3500 m
|
Weight & dimensions |
Width
| 394 mm
|
Depth
| 533 mm
|
Height
| 455 mm
|
Weight
| 33000 g
|
Sustainability |
Sustainability compliance
| Y
|
Packaging content |
Cartridge(s) included
| Y
|
Included cartridge capacity (black)
| 8000 pagina's
|
Included cartridge capacity (CMY)
| 6000 pagina's
|
Cables included
| AC
|
Printer drum included
| Y
|
Quick installation guide
| Y
|
User guide
| N
|
Developer unit included
| Y
|
Batteries included
| Y
|
