Open-frame Outdoor Display
LG Open Frame display empowers you to personalize not only the casing design but also the function, granting you the freedom to tailor the digitial signage frame display to your exact preferences.

World’s First UL Verification for Display Anti-Discoloration Characteristics
By focusing on the pain points of our customers, we obtained the world’s first UL Verification for Display Anti-Discoloration Characteristics. Our new technology helps prevent ‘screen-yellowing’, while maintaining display quality and performance stability.

High Visibility Under Strong Sunlight
With outstanding high brightness of 3, 000 nits (Typ. ), the XF3P open frame outdoor display delivers content clearly while captivating passerby. In addition, its outdoor visibility can deliver a variety of information even to those wearing polarized sunglasses.

Optimized Design for Double-sided Display
The high brightness open frame display XF3P, featuring a sleeker design than the conventional model, excels in maximizing space efficiency with its convenient double-sided display.

Efficient Energy Management
The screen brightness is automatically adjusted depending on the ambient light. The brightness is increased in light for better visibility, while it is decreased in darkness for efficient power management. Also, open frame display XF3P uses M+ panel that can offer high energy efficiency and cost savings by decreasing power consumption.

High-performance with webOS 6.1
Quad Core SoC (System-on-Chip) can execute several tasks at the same time without a separate media player. In addition, webOS 6.1 platform enhances not only user convenience with intuitive UI but also web-app integration with updated Node JS / Chromium version.

Wide Range of Operating Temperature
The open frame display XF3P can be used under a wide range of operating temperature from 0℃ to 50℃.

Conformal Coating
Conformal Coating protects the circuit board and power board against dust, iron powder, humidity, etc.

Installation Guide for a Customized Casing
LG offers an installation guide for designing a customized casing frame to ensure stable performance for outdoor displays. It includes information about the size of ventilation and the location of partitions within the casing.

Web Monitoring
The LG Control Manager, the embedded web monitoring program, is user-friendly and enables the user to have full access anywhere at anytime from their mobile phone or PC while having access to both current and past data. It allows the user to monitor the unit, make adjustments, and control the unit remotely in real time.

Professional Content Partners
Pairing the high brightness open frame display XF3P with LG SW solutions would enhance its utilization.

Specification

Product
Product id	1004859
Brand	LG Electronics
Partnr	55XF3P-B
EAN/UPC code	8806096417997
Warranty (months)	24 months
Display
Display diagonal	55 inch
Display resolution	1920 x 1080 Pixels
Display brightness	3000 cd/m²
HD type	Full HD
Native aspect ratio	16:9
Response time	9 ms
Contrast ratio (typical)	1300:1
Contrast ratio (dynamic)	500000:1
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Display number of colours	16.78 million colours
Native refresh rate	60 Hz
Rated lifetime	50000 uur
Haze rate	3 procent
Colour depth	8 Bit
Colour gamut	72 procent
Panel type	IPS
Ports & interfaces
HDMI ports quantity	2
DisplayPorts quantity	2
DisplayPorts in	1
DisplayPorts out	1
USB port	Y
USB ports quantity	1
USB version	2.0
Ethernet LAN	Y
Ethernet LAN (RJ-45) ports	1
Number of speaker outputs	1
RS-232C	Y
Remote (IR) output	1
Audio
Built-in speaker(s)	N
Design
Product colour	Black
Placement supported	Indoor
VESA mounting	Y
Panel mounting interface	600 x 400 mm
Performance
On Screen Display (OSD)	Y
Number of OSD languages	22
Operating hours (hours/days)	24/7
HDCP	Y
HDCP version	2.2
Power
Power consumption (off)	0.5 W
AC input voltage	100-240 V
AC input frequency	50-60 Hz
Computer system
Internal memory	8 GB
Operating system installed	WebOS
Operating system version	6.1
Weight & dimensions
Display width	1235 mm
Display depth	106 mm
Display height	709 mm
Display weight	26500 g
Packaging content
Handheld remote control	Y
Cables included	HDMI, IR, Power
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 80 procent
Technical details
Compliance certificates	CB, CE, Federal Communications Commission (FCC), KC, VCCI
Other features
Portrait mode	Y
Built-in brightness sensor	Y
USB connector type	USB Type-A
Stand included	N
Manual	Y
LED indicators	Power
Plug and Play	Y
