Large UHD Signage Display with LG webOS Platform and Advanced Security

High Brightness
The digital signage display UH7N-M , with a great brightness of 700 nits, clearly delivers content even in bright stores.

Sturdy Design with Fire Flame Resistance
The outer cover of the digital signage display UH7N-M is designed to effectively resist fire flame spread, making the product a great fit for installation in public spaces.

Eye-catching Large Screen
A large screen effectively captures people's attention. Especially, 86-inch UH7N model supports 120Hz, enabling smooth content operation.

Versatile Operation with Multi-USB
With support for two USB ports, digital signage display UH7N-M offers versatile usage options. For example, operating content on the screen while simultaneously using other connected devices is possible. This includes convenient tasks like downloading PPT files from external storage devices while using a mouse or keyboard during a meeting.

High Resolution Display
The digital signage display UH7N-M offers a resolution that is four times higher than FHD, satisfying customers visually. Additionally, the anti-glare coating on the screen reduces screen reflection in bright lighting environments, increasing visibility and legibility, providing customers with a comfortable screen.

Convenient webOS Platform
The 700 nits digital signage UH7N-M is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, enabling easy connection with external sensors and webOS partner apps to create an SI-friendly environment.

Durability that Provides Reliability
Optimized for business environments, the The digital signage display UH7N-M is guarded against the potential impact of salt, dust, iron powder and humidity through the implementation of conformal coating on the power board. Also, its customer-centric features, such as IP5x, 30-degree tilting and Shock Monitoring, provide both reliability and satisfaction.

Design for Space Utilization
Designed with thin bezels and simple cable management, the 700 nits digital signage UH7N-M saves space.

Enhanced Security Features
The digital signage display UH7N-M provides security features, including LG's Enhanced Kernel Protection (EKP) technology, guarding important data from external access or attacks. LG UHD Signage also holds reliable certification in the field of information security, maintaining customers' data and businesses securely. For example, UH7N-M is ISO/IEC 15408 Common Criteria EAL2 Certified.

SuperSign Solutions
SuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.

Carbon Footprint Verification
The cradle-to-grave carbon footprint of UH7N-M has been verified by the Carbon Trust.

Specification

Product
Product id	1005753
Brand	LG Electronics
Partnr	86UH7N-M
EAN/UPC code	8806096233870
Warranty (months)	24 months
Display
Display diagonal	86 inch
LED backlight	Y
LED backlighting type	Edge-LED
Display resolution	3840 x 2160 Pixels
Display brightness	700 cd/m²
HD type	4K Ultra HD
Touchscreen	N
Native aspect ratio	16:9
Response time	8 ms
Contrast ratio (typical)	1200:1
Contrast ratio (dynamic)	1000000:1
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Display number of colours	1.07 billion colours
Native refresh rate	120 Hz
Haze rate	25 procent
Panel type	ADS
Ports & interfaces
HDMI ports quantity	2
DVI port	N
Consumer Electronics Control (CEC)	Yes
DisplayPorts quantity	1
USB port	Y
USB ports quantity	3
USB version	2.0
Ethernet LAN	Y
Ethernet LAN (RJ-45) ports	1
Wi-Fi	Y
Audio (L/R) out	1
RS-232C	Y
Remote (IR) input	1
Audio
Built-in speaker(s)	Y
Number of built-in speakers	2
RMS rated power	20 W
Design
Product colour	Black
Placement supported	Indoor
Orientation	Horizontal/Vertical
Wall mountable	Y
VESA mounting	Y
Panel mounting interface	600 x 400 mm
Bezel width (top)	13.4 mm
Bezel colour	Black
Bezel width (side)	13.4 mm
Bezel width (bottom)	13.4 mm
Performance
Purpose	Commercial
Digital Rights Management (DRM) type	Pro:Idiom
Ambient light sensor	Y
Operating hours (hours/days)	24/7
HDCP	Y
HDCP version	1.4/2.2
webRTC support	Y
Screen sharing	Y
Power
Power consumption (typical)	205 W
Power consumption (off)	0.5 W
Power consumption (economy mode)	144 W
AC input voltage	100-240 V
AC input frequency	50/60 Hz
Heat generation (typical)	699 BTU/h
Heat generation (max)	1013 BTU/h
Computer system
Internal memory	16 GB
Operating system installed	WebOS
Operating system version	6.0
Weight & dimensions
Base depth	29.7 mm
Base height	1099.8 mm
Base width	1928.8 mm
Base weight	53000 g
Packaging data
Package width	2100 mm
Package depth	253 mm
Package height	1250 mm
Package weight	66700 g
Packaging content
Handheld remote control	Y
Cables included	AC
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 procent
Brand-specific features
LG technologies (AV/TV)	Auto Set ID, Booting Logo Image, Control Manager, Fail over, Gapless Playback, Group Manager, ISM Method, Local Contents Scheduling, Local Network Sync, No Signal Image, RS232C Sync, SI Server Setting, Setting Data Cloning, Smart Energy Saving, Status Mailing, Video Tag
Sensors
Gyroscope	Y
Temperature sensor	Y
Technical details
Sustainability certificates	ENERGY STAR, EPEAT
Other features
Display technology	LED
Power consumption (max)	297 W
