Enjoy the most natural interactive digital experience
Modern meeting spaces drive the demand for advanced touch technology with innovative design. To support interactive sessions, the NEC InGlassTM Touch Board along with the responsive passive pen brings superior paper-like writing with minimal latency to a digital canvas. With its slim bezel design, the technology seamlessly integrates into modern interior styling.

High brightness levels ensure excellent readability and image reproduction even in today’s typically bright meeting spaces where maintaining a motivational environment is paramount. The anti-glare coating minimizes disturbing reflections and helps to eliminate niggling fingerprints on the touch surface.

Specification

Product
Product id	822600
Brand	NEC
Partnr	60005425
EAN/UPC code	5028695123199
Warranty (months)	3 years warranty incl. backlight; additional services available
Display
Display diagonal	55 inch
LED backlighting type	Edge-LED
Display resolution	3840 x 2160 Pixels
Display brightness	500 cd/m²
HD type	4K Ultra HD
Touchscreen	Y
Number of simultaneous touchpoints	20
Native aspect ratio	16:9
Response time	8 ms
Multi-touch	Y
Contrast ratio (typical)	8000:1
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Display number of colours	1.076 billion colours
Display diagonal (metric)	138.8 cm
Maximum frame rate	60 fps
Surface hardness	7H
Haze rate	5 procent
Touch response time	15 ms
Horizontal scan range	26 - 91.1 kHz
Panel type	IPS
Vertical scan range	23 - 86 Hz
Ports & interfaces
HDMI ports quantity	2
DVI port	N
DisplayPorts quantity	1
USB port	Y
USB ports quantity	1
USB version	2.0
Ethernet LAN	Y
Ethernet LAN data rates	100 Mbit/s
RS-232 interface	Y
Audio
Built-in speaker(s)	Y
Number of built-in speakers	2
RMS rated power	10 W
Design
Design	Interactive flat panel
Product colour	Black
Orientation	Horizontal/Vertical
Screen shape	Flat screen
VESA mounting	Y
Panel mounting interface	300 x 300 mm
Anti-glare screen	Y
Bezel width (top)	18.4 mm
Bezel width (side)	18.4 mm
Bezel width (bottom)	18.4 mm
Positioning accuracy	1 mm
Performance
Purpose	Universal
Operating hours (hours/days)	24/7
HDCP	Y
Power
Power consumption (typical)	110 W
Power consumption (standby)	2 W
Energy efficiency class (SDR)	G
AC input voltage	100-240 V
Energy efficiency class (HDR)	G
AC input frequency	50 - 60 Hz
Energy consumption (SDR) per 1000 hours	100 kWu
Energy consumption (HDR) per 1000 hours	90 kWu
Energy efficiency scale	A to G
Computer system
Video formats supported	MP4, MPG, TS
Audio formats supported	AAC, LPCM, MP3, WMV
Image formats supported	JPG
Weight & dimensions
Display width	1284.5 mm
Display depth	70.9 mm
Display height	757.3 mm
Display weight	38500 g
Packaging data
Package width	1430 mm
Package depth	250 mm
Package height	920 mm
Package weight	47000 g
Packaging content
Handheld remote control	Y
Batteries included	Y
Cables included	HDMI, Power
Operational conditions
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	20 - 80 procent
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	10 - 90 procent
Other features
Stylus pen	Y
Number of stylus pens	2
Display technology	LCD
