Meticously Powerful Signage with Professional Protection

The NEC MultiSync® MA431 PG-2 combines professional protection of your investment with unparalleled display performance. Deliver your message with impact and seamless simplicity for the most convincing results.

Guaranteed reliability even under the toughest conditions is achieved with the super robust 4mm thick protective glass designed to withstanding external impacts. The anti-reflective glass surface combined with brightness levels of 500 cd/m² provides crisp and clear images and readability from different viewing angles and distances.

The MultiSync® MA431 PG-2 is the perfect choice for creating a big and durable impression in public spaces with high volumes of people such as for applications in transportation, retail, hospitality and digital out of home as well as for tough environments in industrial applications. Thanks to the Wide Colour Gamut panel, pictures look more appealing than any other display.

Specification

Product
Product id	878599
Brand	NEC
Partnr	60005858
EAN/UPC code	5028695125643
Warranty (months)	3 years
Display
Display diagonal	49 inch
LED backlight	Y
Display resolution	3840 x 2160 Pixels
Display brightness	700 cd/m²
Touchscreen	N
Native aspect ratio	16:9
Response time	8 ms
Contrast ratio (typical)	8000:1
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Display number of colours	1.073 billion colours
Native refresh rate	60 Hz
Haze rate	28 procent
Horizontal scan range	15 - 135 kHz
Panel type	IPS
Vertical scan range	23 - 76 Hz
Ports & interfaces
HDMI ports quantity	5
HDMI input ports quantity	4
HDMI output ports quantity	1
DVI port	N
DisplayPorts quantity	4
DisplayPorts in	2
DisplayPorts out	2
USB port	Y
USB ports quantity	3
USB version	2.0
Ethernet LAN	Y
USB 2.0 Type-B ports quantity	1
Ethernet LAN (RJ-45) ports	2
Ethernet LAN data rates	100 Mbit/s
Wi-Fi	N
USB Power Delivery	Y
USB Power Delivery up to	10 W
RS-232 interface	Y
Audio Return Channel (ARC)	Y
Audio
Built-in speaker(s)	N
Design
Design	Kiosk design
Product colour	Black
Placement supported	Indoor
VESA mounting	Y
Panel mounting interface	300 x 300 mm
Bezel width (top)	16 mm
Bezel width (side)	22.1 mm
Bezel width (bottom)	19.6 mm
Performance
Purpose	Universal
Operating hours (hours/days)	24/7
HDCP	Y
International Protection (IP) code	IP5X, IP2X
Power
Power consumption (typical)	105 W
Power consumption (standby)	0.5 W
Energy efficiency class (SDR)	G
AC input voltage	100-240 V
AC input frequency	50/60 Hz
Energy consumption (SDR) per 1000 hours	106 kWu
Computer system
Computer system	Y
Built-in processor	Y
Processor manufacturer	Intel
Weight & dimensions
Display width	1122.6 mm
Display depth	69.8 mm
Display height	644.2 mm
Display weight	31800 g
Packaging data
Package width	1298 mm
Package depth	224 mm
Package height	860 mm
Package weight	38700 g
Packaging content
Handheld remote control	Y
Batteries included	Y
Cables included	HDMI, Power
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 procent
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	10 - 90 procent
Features
Base material	Metal
Other features
USB connector type	USB Type-A, USB Type-B
Display technology	LED
