With its specialised gamma correction and black-level alignment, the enhanced RX-Series renders images of the highest quality even under unfavourable lighting conditions. The series is built to last and perform in 24/7 security and surveillance environments. Its durability is enhanced by AG Neovo’s Anti-Burn-in™ technology, which prevents ghosting while performing nonstop mission-critical operations; NeoV™ Optical Glass and metal casing shield it from scratches or other damages.

Industry-leading Reliability
The RX-Series is specially designed to transcend the challenge of enduring 24/7 operations. AG Neovo’s Anti-Burn-in™ technology also prevents image ghosting while performing nonstop mission-critical operations. Its metal casing and NeoV™ Optical Glass not only protect the RX-Series from damage but also keep maintenance easy.

Enhanced Gamma Correction
Selectable gamma S-curve visually optimses different kinds of images. The AG Neovo specialised image settings enhance colour, brightness, sharpness and contrast ratio, allowing the RX-Series to improve the light, shadows and colour balance of videos.

Flexible Integration
The RX-Series is equipped with 15-Pin D-Sub, HDMI & DP1.2a inputs for analogue and digital signal support respectively. It also has composite (BNC) inputs/outputs for video looping of surveillance cameras signals and DVRs.

Flicker-Free Backlight
The flicker-free backlight of the RX-Series ensures a comfortable viewing experience by reducing eyestrain after long periods of use.

Specification

Product
Product id	970407
Brand	AG Neovo
Partnr	RX2402
EAN/UPC code	4710739598179
Design
Product colour	Black
Product type	CCTV monitor
Certification	FCC, CB, CE, BSMI, RoHs, WEEE, REACH, CCC, CEL, G O S T-R
Mounting type	Freestanding/Wall-mounted
Tilt adjustment	Y
Tilt angle range	3 - 21 °
Display
Display diagonal	23.6 inch
Display resolution	1920 x 1080 Pixels
Viewing angle, horizontal	178 °
Display type	LCD
Viewing angle, vertical	178 °
Panel type	VA
Display brightness	300 cd/m²
Display number of colours	16.7 million colours
Pixel pitch	0.275 x 0.275 mm
Horizontal scan range	24 - 83 kHz
Vertical scan range	50 - 75 Hz
Contrast ratio (typical)	20000000:1
Response time	5 ms
Performance
Built-in speaker(s)	Y
Number of built-in speakers	2
VESA mounting	Y
Speaker power	2 W
Panel mounting interface	75 x 75, 100 x 100 mm
Picture-by-Picture (PbP)	Y
Picture-in-Picture	Y
On Screen Display (OSD)	Y
Ports & interfaces
HDMI ports quantity	1
VGA (D-Sub) ports quantity	1
HDMI version	1.4
DVI-D ports quantity	1
Composite video in	1
DisplayPorts quantity	1
USB port	Y
USB 2.0 ports quantity	1
Composite video out	2
3.5 mm (1/8-inch) in	Y
3.5 mm (1/8-inch) out	Y
DC-in jack	Y
Power
Power consumption (standby)	0.5 W
Power source type	DC
Power consumption (off)	0.3 W
AC adapter output voltage	12 V
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 procent
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	5 - 96 procent
Technical details
Compliance certificates	CE, EAC, Federal Communications Commission (FCC), ICES, Low Voltage Directive (LVD), REACH, RoHS, UKCA, WEEE
Weight & dimensions
Weight	7900 g
Height	397 mm
Depth	155 mm
Width	562 mm
Width (with stand)	562.4 mm
Depth (with stand)	196 mm
Height (with stand)	392.8 mm
Weight (with stand)	7700 g
Package width	672 mm
Package depth	249 mm
Package height	517 mm
Package weight	10400 g
Packaging content
AC adapter included	Y
Cables included	Audio, VGA
Quantity	1
