PLUG-AND-PLAY
Simple set up with no software to install or configuration needed

NON-BLOCKING SWITCHING
Non-blocking switching architecture for maximum throughput at wire speed

FANLESS DESIGN
Silent operation makes this switch perfect for noise-sensitive environments

VERSITILE MOUNTING OPTIONS
Install your switch on your desktop or mount it to your wall with the hardware provided in the box

ENERGY EFFICIENT
Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected

FLEX PoE
Easily increase you power budget on this switch to meet your changing power needs.

Specification

Product
Product id	986672
Brand	Netgear
Partnr	GS308LP-100EUS
EAN/UPC code	5715328108707
Warranty (months)	24 months
Data transmission
MAC address table	4000 entries
Switching capacity	16 Gbit/s
Forwarding rate	1.488 Mpps
Throughput	16 Gbit/s
Latency (1 Gbps)	2.6 µs
Number of queues	8
Jumbo frames support	Y
Jumbo frames	9216
Packet forwarding rate (1 Gbps)	1488000 pps
Packet buffer memory	0.192 MB
Network
Networking standards	IEEE 802.3az, IEEE 802.1p, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at
10G support	N
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Cable types supported	Cat5e
Half duplex	Y
Full duplex	Y
MAC address auto-learning supported	Y
MAC address auto-aging supported	Y
Flow control support	Y
Auto-negotiation	Y
Auto MDI/MDI-X	Y
Auto-sensing	Y
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Management features
Switch type	Unmanaged
Quality of Service (QoS) support	Y
Traffic classification	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Security
Queue scheduling algorithms	Weighted Round Robin (WRR)
MAC address entries	Dynamic MAC address entries
Weight & dimensions
Width	236 mm
Depth	102 mm
Height	27 mm
Weight	600 g
Power
Power source	DC
Power supply included	Y
Number of power supply units	1
DC input voltage	54 V
Input current	1.25 A
Power consumption (max)	67.5 W
Endurance
Mean time between failures (MTBF)	2752476 uur
Design
Rack mounting	Y
Stackable	N
Form factor	Desktop
Product colour	Black
Housing material	Metal
LED indicators	Y
Wall mountable	Y
Operational conditions
Operating altitude	0 - 3000 m
Heat dissipation	230.85 BTU/h
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	0 - 95 procent
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 procent
Performance
Fanless	Y
Technical details
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC), RCM, VCCI, KC, CB, Low Voltage Directive (LVD)
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet (PoE) type supported	PoE+
Power over Ethernet (PoE) ports quantity	8
Power over Ethernet plus (PoE+) ports quantity	8
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	60 W
Other features
Input voltage	54 V
