The Neomounts by Newstar wall mount, model LED-W120 is a fixed wall mount for flat screens up to 40" (102 cm). This mount is a great choice when you want the ultimate viewing flexibility with your flat screen. Depth of this mount is 1, 5 to 3 centimetres.

Neomounts by Newstar LED-W120 is suitable for screens up to 40" (102 cm). The weight capacity of this product is 50 kg each screen. The wall mount is suitable for screens that meet VESA hole pattern 100x100 to 200x200mm. Different hole patterns can be covered using Neomounts by Newstar VESA adapter plates.

Create a clean design ambiance for your flat screen TV in the living room, bedroom or home cinema.

All installation material is included with the product.

Specification

Product
Product id	333010
Brand	Neomounts
Partnr	LED-W120
EAN/UPC code	8717371442958
Warranty (months)	5 year
Mounting
Maximum weight capacity	50 kg
Mounting type	Wall
Minimum screen size compatibility	22 "
Maximum screen size	40
Minimum VESA mount	100 x 100 mm
Maximum VESA mount	200 x 200 mm
Panel mounting interface	100 x 100, 100 x 150, 100 x 200, 120 x 120, 200 x 100, 200 x 200 mm
Ergonomics
Type	Fixed
Technical details
Product colour	Black
Number of displays supported	1
Distance to the wall (max)	30 mm
Package net weight	960 g
Distance to the wall (min)	15 mm
Design
Housing material	Steel
Weight & dimensions
Weight	960 g
Packaging data
Package width	120 mm
Package depth	40 mm
Package height	305 mm
Package weight	1000 g
Other features
Country of origin	China
Logistics data
Master (outer) case width	625 mm
Master (outer) case length	375 mm
Master (outer) case height	140 mm
Master (outer) case weight	20160 g
Master (outer) case net weight	17280 g
Quantity per master (outer) case	18 stuk(s)
Harmonized System (HS) code	HS83025000
Quantity per EUR-pallet	576 stuk(s)
