The Neomounts by Newstar menu board wall mount, model NS-WMB200BLACK is a tiltable wall mount for two flat screens up to 52" (132 cm). This mount is a great choice when you want the ultimate viewing flexibility with your flat screen. Neomounts by Newstars tilt (0°/-5°/-10°/-15°/-20°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. Depth of this mount is 7, 8 centimetres.

Neomounts by Newstar NS-WMB200BLACK is suitable for 2 screens up to 52" (132 cm). The weight capacity of this product is 50 kg each screen. The wall mount is suitable for screens that meet VESA hole pattern 200x200 to 600x400 mm.

All installation material is included with the product.

Specification

Product
Product id	648929
Brand	Neomounts
Partnr	NS-WMB200BLACK
EAN/UPC code	8717371447373
Warranty (months)	5 year
Mounting
Maximum weight capacity	50 kg
Minimum screen size compatibility	40 "
Maximum weight capacity (per display)	50 kg
Mounting type	Wall
Maximum screen size	52
Minimum VESA mount	200 x 200 mm
Maximum VESA mount	600 x 400 mm
Panel mounting interface	200 x 200, 600 x 400 mm
Ergonomics
Swivel angle	6 °
Tilt angle range	0 - 20 °
Cable management	Y
Distance to the wall (min)	76 mm
Height adjustment	480 mm
Tilt adjustment	Y
Tilt angle	20 °
Width adjustment	1800 mm
Design
Product colour	Black
Housing material	Steel
Weight & dimensions
Width	1800 mm
Height	48 mm
Weight	9390 g
Package width	240 mm
Package depth	165 mm
Package height	740 mm
Packaging data
Package weight	10900 g
Technical details
Angle of rotation	6 °
Number of displays supported	2
Package net weight	10900 g
Other features
Country of origin	China
Logistics data
Quantity per master (outer) case	1 stuk(s)
Master (outer) case net weight	10900 g
Harmonized System (HS) code	HS83025000
Quantity per EUR-pallet	45 stuk(s)
Master (outer) case width	240 mm
Master (outer) case length	165 mm
Master (outer) case height	740 mm
Master (outer) case weight	10900 g
Quantity per master (outer) case	1 stuk(s)
