Create a mobile workstation wherever you work with a single 4K 60Hz HDMI display, 2x USB-A 10Gbps ports, 2.5Gbps Ethernet, an SD Card slot, and 140W USB Power Delivery 3.1 pass-through for laptop charging

Turn a single USB-C port into a complete mobile workstation with video, power, data, storage, and wired networking in one compact adapter.

Deploy Clean, Clutter-Free Workstations Anywhere

Transform one USB-C port into 4K 60Hz HDMI, 140W Power Delivery passthrough, and multiple USB ports. Reduce dongles in shared desks, hoteling spaces, travel kits, and field deployments. Standardize on one adapter to simplify provisioning and support across laptop deployments.

Power High-Performance and AI-Ready Laptops

Deliver up to 140W USB-C Power Delivery passthrough to support demanding workloads and high-performance systems. When power is not required, enable up to 10Gbps USB-C data transfer for fast external drives and peripherals. Give users flexible power or data based on their task and setup.

Expand Connectivity and Strengthen Network Performance

Access SD 3.0 UHS-I media for file transfers and connect phones, tablets, and storage through two 10Gbps USB-A ports. Add 2.5GbE for reliable wired networking in environments where Wi-Fi congestion, latency, or security policies impact productivity.

Built for Sustainability, Designed for Performance

This hub features a housing made from 75% post-consumer recycled (PCR) aluminum, 75% PCR Plastic, and a cable jacket composed of 35% PCR TPE (Thermoplastic Elastomer). The product also ships in FSC Mix packaging made from responsibly sourced materials. These materials help align your IT infrastructure with your organization's sustainability goals, without compromising on quality or durability.

Specification

Product
Product id	1022047
Brand	StarTech.com
Partnr	177B-USBC-MULTIPORT
EAN/UPC code	065030904162
Warranty (months)	3 Years
Ports & interfaces
Connectivity technology	Wired
Host interface	USB 3.2 Gen 2 (3.1 Gen 2) Type-C
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
USB Power Delivery	Y
USB Power Delivery revision	3.2
USB Power Delivery up to	140 W
HDMI ports quantity	1
HDMI version	2.0
Microphone in	N
USB Type-C DisplayPort Alternate Mode	Y
Network
Ethernet LAN	Y
Ethernet LAN (RJ-45) ports	1
Ethernet LAN data rates	10, 100, 1000, 2500 Mbit/s
Full duplex	Y
Performance
Product colour	Grey
Card reader integrated	Y
Compatible memory cards	SD
Data transfer rate	10 Gbit/s
HD type	4K Ultra HD
Maximum digital resolution	3840 x 2160 Pixels
Number of displays supported	1
Housing material	Aluminium, Plastic
UASP support	Y
Mean time between failures (MTBF)	28434 uur
Power
Power source type	USB
Power consumption (max)	20 W
USB cable length	0.12 m
Software
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64
Mac operating systems supported	Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma, Mac OS X 15.0 Sequoia, Mac OS 26 Tahoe
Linux operating systems supported	Y
Mobile operating systems supported	iPadOS, iOS
Weight & dimensions
Width	50 mm
Depth	125 mm
Height	15 mm
Weight	100 g
Packaging data
Package width	190 mm
Package depth	57 mm
Package height	19 mm
Package weight	141 g
Packaging content
User guide	Y
Operational conditions
Operating temperature (T-T)	-10 - 45 °C
Storage temperature (T-T)	-10 - 70 °C
Operating relative humidity (H-H)	10 - 90 procent
Technical details
Compliance certificates	RoHS, CE
Logistics data
Master (outer) case height	260 mm
Master (outer) case length	205 mm
Master (outer) case width	425 mm
Quantity per master (outer) case	80 stuk(s)
Other features
Chipset	VIA - VL600, VIA - VL109, VIA - VL822, Realtek - RTL8156BG, Genesys Logic - GL3224
