Create a mobile workstation wherever you work

Enable dual-4K displays, high-speed device connectivity, power, and networking from a single USB-C dock for consistent productivity anywhere.

Deploy Multi-Display Setups with Ease

Drive two 4K 60Hz DisplayPort displays on Windows, Linux, and ChromeOS to increase screen real estate. Ideal for hot desks and remote users who need instant multi-monitor setups.

Connect Devices and Keep Ports Free

Connect modern and legacy high-speed devices with 3x USB-C and 2x USB-A (5Gbps), while a dedicated USB-A 2.0 port handles keyboard and mouse dongles or other essential peripherals. Reduce hub sprawl and keep critical ports available for storage, capture, or field tools.

Deliver a Consistent Desktop Experience Anywhere

Provide 100W PD charging passthrough and Gigabit Ethernet for stable, wired performance at home, in the office, or while travelling. Standardize deployments with the same display, USB, and network experience to simplify rollouts and support.

Built for Sustainability, Designed for Performance

This hub features a housing made from 85% post-consumer recycled (PCR) plastic. The product also ships in FSC Mix packaging made from responsibly sourced materials. These materials help align your IT infrastructure with your organization's sustainability goals, without compromising on quality or durability.

Specification

Product
Product id	1022036
Brand	StarTech.com
Partnr	189B-USBC-MULTIPORT
EAN/UPC code	065030917100
Warranty (months)	3 Years
Ports & interfaces
Connectivity technology	Wired
Host interface	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 2.0 Type-C ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	3
USB Power Delivery	Y
USB Power Delivery up to	100 W
DisplayPorts quantity	2
DisplayPort version	1.2
Microphone in	N
Network
Ethernet LAN	Y
Ethernet LAN (RJ-45) ports	1
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Wake-on-LAN ready	Y
Full duplex	Y
Performance
Product colour	Grey
Card reader integrated	N
Data transfer rate	5 Gbit/s
HD type	4K Ultra HD
Maximum digital resolution	3840 x 2160 Pixels
Housing material	Plastic
Mean time between failures (MTBF)	103855 uur
Power
Output voltage	5 V
Power consumption (typical)	15 W
USB cable length	0.3 m
Software
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64
Linux operating systems supported	Y
Other operating systems supported	ChromeOS
Weight & dimensions
Width	55 mm
Depth	150 mm
Height	16.5 mm
Weight	100 g
Packaging data
Package width	193 mm
Package depth	117 mm
Package height	24 mm
Package weight	190 g
Packaging content
User guide	Y
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	10 - 70 °C
Operating relative humidity (H-H)	10 - 85 procent
Logistics data
Master (outer) case height	270 mm
Master (outer) case length	425 mm
Master (outer) case width	540 mm
Quantity per master (outer) case	80 stuk(s)
Other features
Chipset	Synaptics - VMM5220, VIA - VL103, VIA - VL817S, Realtek - RTL8153E
