2-Port Multi-Gigabit PoE/PoE++Injector



StarTech.com
Not in stock
€ 94,67
€ 114,55 incl 21% VAT
Supply power and data to two PoE devices over standard Ethernet cabling

This 2-port multi-speed PoE+ injector serves as Power Sourcing Equipment (PSE) and enables Ethernet speeds of 10/100/1000Mbps. This mid-span inline injector can transmit network data and power up to 328ft (100m) for two Powered Devices (PD).

Versatile PoE Injector

Dual-port PoE injector supports the IEEE 802.3af and IEEE 802.3at PSE standards and delivers up to 30W output (52V/0.580A). Connect a remote PoE device to a network at a location where there is no power source, but an Ethernet cable already exists. This includes access points, IP cameras, VoIP phone systems, IPTV and access controls. The flexible design allows for either desktop or surface-mount use.

Streamlined Cable Management

All Ethernet cables can be routed from one side of the unit for efficient and organized cable management. The compact design (3.2x1x1.8in(82x25x46mm) ensures straightforward integration into existing network infrastructure, saving space and time during installation.

The StarTech. com Advantage

Specification

Product
Product id 974726
Brand StarTech.com
Partnr AF221CE-POE-INJECTOR
EAN/UPC code 065030911313
Warranty (months) 2 Years
Network
Ethernet interface type Gigabit Ethernet, Fast Ethernet
Ethernet LAN data rates 10, 1000, 100 Mbit/s
Power over Ethernet (PoE) Y
Chipset IC Plus - IP802AR
Networking standards IEEE 802.3ab, IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3at
Cabling technology 10/100/1000
Web-based management N
Auto MDI/MDI-X Y
Features
Wall mountable Y
Housing material Plastic
Surge protection Y
Maximum operating distance 100 m
Product colour Black
LED indicators Y
Jumbo frames support Y
Jumbo frames 9000
Auto-negotiation Y
Ports & interfaces
Ethernet LAN (RJ-45) ports 4
RJ-45 input ports 2
RJ-45 output ports 2
DC-in jack Y
Power
Output power 30 W
AC adapter input voltage 100 - 240 V
AC adapter output voltage 52 V
Input current 1.5 A
Output current 1.25 A
Power consumption (max) 65 W
Total Power over Ethernet (PoE) budget 30 W
Power plug type Type M
Surge protection voltage 2 kV
Suitable for use in country/location Europe, United Kingdom
Technical details
Compliance certificates RoHS
Operational conditions
Operating relative humidity (H-H) 5 - 90 procent
Storage temperature (T-T) -10 - 70 °C
Weight & dimensions
Width 46 mm
Depth 102 mm
Height 25 mm
Weight 60 g
Packaging data
Package width 207 mm
Package depth 144 mm
Package height 38 mm
Package weight 105 g
Packaging content
Quick installation guide Y
Logistics data
Master (outer) case width 440 mm
Master (outer) case length 420 mm
Master (outer) case height 320 mm
Quantity per master (outer) case 40 stuk(s)
