2m DisplayPort 1.2 Cable 4K 60Hz



StarTech.com
In stock
€ 97,10
€ 117,49 incl 21% VAT
Set up multiple 4K UHD connections using this DisplayPort Cable 10 Pack

Faciliate multi-monitor setups using this DisplayPort 1.2 Cable 10-Pack. This cable facilitates high bandwidth video and multi-channel audio and is ideal for 4K workstations, docks, and high performance GPUs. Connect a 4K 60Hz UHD DisplayPort monitor to a host computer or MST hub.

Seamless Compatibility

For seamless operation between DisplayPort-enabled devices, the DisplayPort 1.2 Cable is VESA Certified for guaranteed DP 1.2 and backward compatibility with DP 1.1.

Durable Design

This DisplayPort cable features a flexible TPE outer jacket and can be routed around corners and desk edges. Robust strain reliefs enable convenient positioning of the cable, and latching gold-plated DP connectors attach securely to prevent accidental disconnection.

Supported DisplayPort 1.2 Features:

The Certified DisplayPort Cable supports the following DP 1.2 features:

• Resolutions up to 4K 60Hz, using a compatible DP source and display
• Supports high refresh rates including 1080p 120Hz and 1440p 75Hz
• High-Bandwidth Digital Content Protection (HDCP) for a secure connection between source and display
• Multi-Stream Transport (MST) for daisy-chaining multiple monitors
• 8 Uncompressed Digital Audio Channels
• Backward compatible with DP 1.1

This DP 1.2 Cable is constructed with braided aluminum mylar shielding to minimize EMI for clear, consistent audio/video output and long-term reliable performance.

The StarTech. com Advantage

Specification

Product
Product id 973179
Brand StarTech.com
Partnr DISPL2M10PK
EAN/UPC code 065030910071
Warranty (months) Lifetime
Features
Cable length 2 m
Connector 1 DisplayPort
Connector 2 DisplayPort
Connector 1 gender Male connector
Connector 2 gender Male connector
Connector 1 form factor Straight
Connector 2 form factor Straight
Connector contacts plating Nickel
Maximum resolution 3840 x 2160 Pixels
Maximum refresh rate 120 Hz
HDCP Y
Latching connectors Y
Product colour Black
Cable rating CMG (CM)
Cable shielding Aluminum mylar foil
Jacket material Thermoplastic Elastomer (TPE)
AWG wire size 28
Data transfer rate 21.6 Gbit/s
Multi-Stream Transport (MST) Y
Number of conductors 19
Cable type Round cable
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -20 - 70 °C
Operating relative humidity (H-H) 10 - 85 procent
Packaging data
Cable diameter 7.3 mm
Weight 134 g
Quantity per pack 10 stuk(s)
Package width 350 mm
Package depth 460 mm
Package height 100 mm
Package weight 1400 g
Logistics data
Master (outer) case width 320 mm
Master (outer) case length 500 mm
Master (outer) case height 210 mm
Quantity per master (outer) case 5 stuk(s)
Technical details
Compliance certificates CE, RoHS
