GIGABIT FIBER 1000BASE-SX SFP TRANSCEIVER MODULE - CISCO GLC-SX-MMD COMPATIBLE - MM LC - 550M (1804 FT)



StarTech.com
In stock
€ 44,42
€ 53,74 incl 21% VAT
1000 Mbps (1 Gbps) | Multi Mode Fiber | LC | 550 m (1804 ft) | Lifetime Warranty

The GLCSXMMDST is a Cisco GLC-SX-MMD compatible fiber transceiver module that has been designed, programmed and tested to work with Cisco brand switches and routers. It delivers dependable 1 GbE connectivity over fiber cable, for 1000BASE-SX compliant networks, with a maximum distance of up to 550 m (1804 ft).

Technical Specifications:

Wavelength: 850 nm

Maximum Data Transfer Rate: 1.25 Gbps

Type: Multi Mode Fiber

Connection Type: LC Connector

Maximum Transfer Distance: 550 m (1804 ft)

MTBF: 3, 381, 761 hours

Power Consumption: Less than 1 Watt

Digital Diagnostics Monitoring (DDM): No

This SFP fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech. com SFPs

All StarTech. com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech. com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.

The StarTech. com Advantage

- 100% compatibility with Cisco GLC-SX-MMD guaranteed
- StarTech. com SFP modules are backed by a lifetime warranty
- Meets or exceeds OEM specifications and Multi-Source Agreement (MSA) industry standards

Specification

Product
Product id 567673
Brand StarTech.com
Partnr GLCSXMMDST
EAN/UPC code 065030868587
Warranty (months) Lifetime
Network
SFP transceiver type Fiber optic
Technical details
Sustainability certificates RoHS
Packaging data
Number of products included 1 stuk(s)
Package width 119 mm
Package depth 92 mm
Package height 32 mm
Package weight 46 g
Performance
Maximum data transfer rate 1250 Mbit/s
Interface type SFP
Multi-mode fiber (MMF) supported Y
Fiber optic connector LC
SFP transceiver standard SX
Maximum transfer distance 550 m
Wavelength 850 nm
Networking standards IEEE 802.3z
Duplex system Full
Digital Diagnostics Monitoring (DDM) Y
Features
Product colour Silver
Housing material Aluminium
Hot-swap Y
Mean time between failures (MTBF) 3381761 uur
Certification CE, FCC, UR
Power
Power consumption (typical) 1 W
Operational conditions
Operating temperature (T-T) 0 - 70 °C
Storage temperature (T-T) -40 - 85 °C
Operating relative humidity (H-H) 5 - 95 procent
Weight & dimensions
Width 13.7 mm
Depth 56.6 mm
Height 12.5 mm
Weight 18 g
