Expand your network connectivity with simple plug-and-play setup

This unmanaged, fanless network switch delivers silent, energy-efficient performance with five multi-speed Ethernet ports (10/100/1000 Mbps). Its durable all-metal casing ensures long-lasting reliability.

Enhance Your Network

Expand your network connectivity with simple plug-and-play setup. This network switch is ideal for large file transfers, streaming, network sharing and storage, or other bandwidth-intensive applications. Auto-negotiation detects the highest supported speeds on your devices for maximum performance and compatibility.

Rugged TAA Switch

This TAA compliant unmanaged switch features an unintrusive design and small dimensions (3.9x2.3x1 inch / 100.5x60x 25.5mm). Key features such as 9K Jumbo Frames, 3-Pin Terminal Block Power Input, QoS IEEE 802.1p, and the included DIN Rail and Wall Mounting Kits give you the flexibility to use it in a multitude of scenarios. The rugged metal enclosure is IP30 rated to prevent objects larger than 2.5mm from getting inside and has an extended operating temperature range of -40°F-167°F (40°C-75°C). The clear diagnostic LEDs show the status of the devices at a glance.

Designed for Demanding Environments

This network switch is deal for industrial settings and centralized control stations where device reliability is essential and environmental conditions fluctuate. The compact form factor makes it an ideal solution for Industrial Automation and IP Surveillance.

The StarTech. com Advantage

Specification

Product
Product id	976870
Brand	StarTech.com
Partnr	I51G-ETHERNET-SWITCH
EAN/UPC code	065030909648
Warranty (months)	2 Years
Data transmission
Store-and-forward	Y
Jumbo frames support	Y
Jumbo frames	9000
Network
Networking standards	IEEE 802.1p, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
10G support	N
Copper ethernet cabling technology	100BASE-TX, 1000BASE-T
Full duplex	Y
Auto MDI/MDI-X	Y
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Management features
Switch type	Unmanaged
Quality of Service (QoS) support	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	5
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	5
Power connector	Terminal block (3-pin)
Weight & dimensions
Width	60 mm
Depth	100 mm
Height	26 mm
Weight	221.7 g
Packaging data
Quick start guide	Y
DIN rail included	Y
Package weight	293.7 g
Terminal block included	Y
Mounting brackets included	Y
Package width	107 mm
Package depth	159 mm
Package height	55 mm
Power
Power supply included	Y
Endurance
Mean time between failures (MTBF)	556710 uur
Design
Product colour	Black
Housing material	Metal
LED indicators	Y
DIN rail mounting	Y
Wall mountable	Y
International Protection (IP) code	IP30
Operational conditions
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 procent
Technical details
Compliance certificates	RoHS, Trade Agreements Act (TAA)
Logistics data
Master (outer) case width	355 mm
Master (outer) case length	295 mm
Master (outer) case height	335 mm
Quantity per master (outer) case	30 stuk(s)
Other features
Input voltage	9 - 60 V
