Product |
Product id |
581047 |
Brand |
StarTech.com |
Partnr |
QSFP40LR4ST |
EAN/UPC code |
065030873345 |
Warranty (months) |
Lifetime |
Network |
SFP transceiver type |
Fiber optic |
Technical details |
Sustainability certificates |
RoHS |
Packaging data |
Number of products included |
1 stuk(s) |
Package width |
92 mm |
Package depth |
117 mm |
Package height |
32 mm |
Package weight |
76 g |
Performance |
Maximum data transfer rate |
40000 Mbit/s |
Interface type |
QSFP+ |
Single-mode fiber (SMF) supported |
Y |
Multi-mode fiber (MMF) supported |
N |
Fiber optic connector |
LC |
SFP transceiver standard |
LR4 |
Maximum transfer distance |
10000 m |
Tx wavelength (min) |
1270 nm |
Tx wavelength (max) |
1330 nm |
Networking standards |
IEEE 802.3ba |
Duplex system |
Full |
Digital Diagnostics Monitoring (DDM) |
Y |
Features |
Product colour |
Silver |
Housing material |
Aluminium |
Hot-Plug support |
Y |
Mean time between failures (MTBF) |
1489426 uur |
Certification |
CE, FCC, UR, REACH |
Power |
Power consumption (typical) |
2.5 W |
Operational conditions |
Operating temperature (T-T) |
0 - 70 °C |
Storage temperature (T-T) |
-40 - 85 °C |
Operating relative humidity (H-H) |
5 - 95 procent |
Weight & dimensions |
Width |
18.4 mm |
Depth |
72 mm |
Height |
13 mm |
Weight |
40 g |
Logistics data |
Master (outer) case width |
250 mm |
Master (outer) case length |
300 mm |
Master (outer) case height |
200 mm |
Quantity per master (outer) case |
36 stuk(s) |
