Omada Pro AX3600 Ceiling Mount WiFi 6 Ac



TP-Link
Not in stock
€ 1.288,51
€ 1.559,09 incl 21% VAT
What This Product Does

AP9665, the Omada Pro AX3600 Ceiling Mount WiFi 6 Access Point, provides overall 3550 Mbps speeds with WiFi 6 technologies, such as 1024 QAM, Long OFDM Symbol, and more. Two built-in Gigabit Ethernet ports ensure high network throughput. PoE++ support also provides flexible installations.

Integrated into the Omada solution, AP9665 runs in an efficient management way. Centralized and remote management liberates and reduces maintenance costs.

Superb WiFi 6 Speed and High-Density Connectivity

· Blazing-Fast AX3600 Wi-Fi 6 Speeds
High-end business WiFi 6 brings speeds up to 3550 Mbps. 1024 QAM ensures that 25% more data is encoded at one time. The long OFDM Symbol helps with 11% faster WiFi speed.

· High-Density Connectivity for More Devices
AP9665 is designed for high-density scenes with up to 1, 000+ clients. Wi-Fi 6 features such as OFDMA and MU-MIMO handle multiple clients across congested environments like typical office spaces, lodging, and hospitals. Enjoy faster speeds on more devices with less lag.
Easy Deployment and Installation

· Ultra-thin Casing
The overall design of AP9665 utilizes a thinner circular arc with a groove around the top cover (8.7 × 8.7 × 1.3 in), fitting closer to various installation surfaces such as ceilings. The compact internal hardware layout and heat-dissipating design ensure high performance with a sharp aesthetic.

· PoE++ Support
Supporting 802.3bt (PoE++), AP9665 empowers flexible and easy installation.

Boosted Network Security and Efficiency

Customizable WIDS and adaptive WIPS assist in safeguarding critical data and network resources. Intelligent Anomaly Detection and Analysis guarantees 24/7 automatic network anomaly analysis to offer timely optimization advice. AP9665 also provides secure WiFi access along with multiple authentication options (SMS/Voucher/RADIUS) and abundant wireless security technologies, such as WPA3, for worry-free open public networks.

Auto Channel Selection and Power Adjustment provides powerful wireless performance while significantly reducing WiFi interference by automatically adjusting the channel settings and transmission power levels of neighboring APs in the same network. Band steering automatically moves dual-band devices onto the wider 5GHz band for faster connections. Load balance ensures large numbers of users have smooth network experiences in high-density business networks. Airtime fairness increases average network throughput in heavily congested environments.

Cloud-Based Centralized Management

The Omada Software-Defined Networking (SDN) platform provides 100% centralized cloud management and creates a highly scalable network controlled by a single interface. Seamless wireless connections are provided, making them ideal for use in hospitality, education, retail, offices, and more. Zero-Touch Provisioning allows admins to remotely deploy and configure multi-site networks, so there’s no need to send out an engineer for on-site configuration.

Specification

Product
Product id 943015
Brand TP-Link
Partnr AP9665
EAN/UPC code 4895252503531
Warranty (months) 3 year limited warranty
Management features
Web-based management Y
Syslog Y
Packaging data
Number of products included 1 stuk(s)
Mounting kit Y
Quick start guide Y
Features
2.4 GHz Y
5 GHz Y
Maximum data transfer rate 3600 Mbit/s
6 GHz N
Maximum data transfer rate (2.4 GHz) 1148 Mbit/s
Maximum data transfer rate (5 GHz) 2402 Mbit/s
Ethernet LAN data rates 10, 100, 1000, 2500 Mbit/s
Frequency band 2.4 - 5 GHz
Networking standards IEEE 802.11n, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ad, IEEE 802.11ax, IEEE 802.11az, IEEE 802.11b
Number of users 1000 gebruiker(s)
Automatic channel selection Y
Automatic channel scanning Y
MIMO Y
MIMO type Multi User MIMO
Wi-Fi Multimedia (WMM)/(WME) Y
VLAN support Y
Rate limiting Y
Band steering Y
Airtime Fairness (ATF) Y
Quality of Service (QoS) support Y
BeamForming Y
Security
Security algorithms WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise
MAC address filtering Y
Service Set Identifier (SSID) features Multiple SSIDs
Number of SSID supported 16
Remote Authentication Dial-In User Service (RADIUS) Y
Access Control List (ACL) Y
Ports & interfaces
Ethernet LAN (RJ-45) ports 2
USB 2.0 ports quantity 1
DC-in jack Y
Power
Power over Ethernet (PoE) Y
DC voltage range 12 V
Input current 1.5 A
Design
Placement Ceiling, Wall
Product colour White
Reset button Y
Antenna
Antenna type Internal
Antenna gain level (max) 4 dBi
Operational conditions
Operating relative humidity (H-H) -10 - 90 procent
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -40 - 70 °C
Storage relative humidity (H-H) 5 - 90 procent
Technical details
Sustainability certificates CE, Federal Communications Commission (FCC), RoHS
Sustainability compliance Y
Weight & dimensions
Width 220 mm
Depth 220 mm
Height 32.5 mm
