4G and 3 LAN Ports, Hassle-free Deployment
4MP Outdoor Full-Color 4G Bullet Network Camera

3 LAN Ports Meet Minimal Deployment Effort

InSight S345-4G offers industry-first three LAN ports, enabling simultaneous connectivity for up to three devices as you need. It is ideal for coupling with solar power systems to eliminate additional wiring deployments.

Human & Vehicle Classification
Distinguish humans and vehicles from other objects and receive more accurate event notifications.

LightPro Night Vision Technology

The VIGI LightPro Night Vision Technology intelligently switches between IR night vision and full-color night vision by detecting people or vehicles. This allows the camera to capture clearer and more critical details with the white light on, and to reduce light pollution and energy consumption with the IR light on at most time, effectively adapting to a broader range of scenarios.

Smart Video Enhancement Technology
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting. △

Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.

3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.

White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.

Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.

Specification

Product
Product id	1009211
Brand	TP-Link
Partnr	INSIGHT S345-4G(4MM)
EAN/UPC code	8885020625585
Warranty (months)	3 year limited warranty
Performance
Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
Maximum operating distance	80 m
Wide Dynamic Range (WDR)	Y
Day/night mode	Y
Remote viewing	Y
Antenna type	External
Antennas quantity	2
Infrared (IR) cut-off filter	Y
Dynamic range	120 dB
Design
Form factor	Bullet (shape)
Mounting type	Wall
Product colour	White
Housing material	Metal
Protection features	Waterproof
International Protection (IP) code	IP66
Weatherproof	Y
Camera
Lens viewing angle, horizontal	80.4 °
Lens viewing angle, vertical	41.8 °
Tilt angle range	0 - 90 °
Lens viewing angle, diagonal	98.7 °
Camera shutter speed	1/3 to 1/10000 s
Image sensor
Sensor type	CMOS
Optical sensor size	1/2.7 "
Progressive scan	Y
Lens system
Detect distance	80 m
Observe distance	33 m
Recognize distance	16 m
Fixed focus	Y
Maximum aperture number	1.6
Identify distance	8 m
Fixed focal length	4 mm
Night vision
Night vision	Y
LED type	IR/White
Video
Maximum resolution	2688 x 1520 Pixels
Total megapixels	4 MP
Video compression formats	H.264, H.264+, H.265, H.265+
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520
Video recording	Y
Digital Wide Dynamic Range (DWDR)	Y
Highlight Compensation (HLC)	Y
Back Light Compensation (BLC)	Y
Bit rate	Main Stream: 256 Kbps to 6 Mbps, Sub-Stream: 64 Kbps to 512 Kbps
Image quality adjustment	Brightness, Contrast, Mirror, Saturation, Sharpness
Bit rate control	Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Audio
Built-in speaker(s)	Y
Audio system	2-way
Audio input channels	1.0
Audio output channels	1.0 kanalen
Audio formats supported	G.711 A-law
Built-in microphone	Y
Sample rate	8 kHz
Number of microphones	1
Bit rate range	0 - 64 Kbit/s
Network
Ethernet LAN	Y
Wi-Fi	N
Bluetooth	N
Supported network protocols	TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
SIM card type	NanoSIM
Live view	Y
SIM card slot	Y
4G standard	LTE-TDD & LTE-FDD
Mobile network generation	4G
Storage
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	512 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports	3
DC-in jack	Y
Security
Built-in siren	Y
Password protection	Y
Video motion detection	Y
Motion sensor	Y
Mirror	Y
Human and vehicle targets classification	Y
Alert notification type	Push notification
Digest authentication	Y
IP address filtering	Y
HTTPS encryption	Y
Detection distance	120 m
Management features
Web-based management	Y
Web browser	Y
Cloud-managed	Y
Reset button	Y
Power
Power source type	DC
Power consumption (max)	9.7 W
Power consumption (Power over Ethernet (PoE))	10.7 W
DC output voltage	12
Operational conditions
Operating temperature (T-T)	-30 - 60 °C
Storage temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	0 - 95 procent
Storage relative humidity (H-H)	0 - 95 procent
Weight & dimensions
Width	122 mm
Height	101 mm
Length	256 mm
Weight	1090 g
Packaging content
Number of cameras	1
Mounting kit	Y
Screws included	Y
Manual	Y
Drilling template included	Y
