See True Colors and Details in the Dark
Unveiling every detail in the dark, experiencing clarity and color as vivid as daylight — no extra fill lights needed.

Worry-Free Night Surveillance: Beyond IR & Full-Color
Eliminates general night vision issues like dark corners, glare, and color loss — enjoy worry-free nighttime monitoring.

See Vividly — Even No Extra Fill Lights Needed
Enables full-color imaging in low-light conditions without fill-in lighting, reducing both energy consumption and insect-triggered false alarms for a more eco-friendly solution.

People or Vehicle Triggered Intelligent IR-White Lights Reveal More in Total Darkness
In complete darkness with zero illumination, VIGI’s intelligent infrared-white lights will automatically activate white lights upon detecting people or vehicles, delivering vivid color imaging while deterring intruders.

VIGI AI Detection Technology
People & Vehicle Analytics: Search and filter to people or vehicle of interest based on many different attributes, like hair length, upper body color, vehicle type, making post-event search faster and easier.

Human & Vehicle Classification: Distinguish humans and vehicles from other objects, such as moving animals, falling leaves, changing lights, and receive more accurate event notifications.

Smart Video Enhancement Technology
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.

Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.

3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.

White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.

Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.

Specification

Product
Product id	1009212
Brand	TP-Link
Partnr	INSIGHT S345S(4MM)
EAN/UPC code	8885020625608
Warranty (months)	3 year limited warranty
Performance
Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Y
Alarm input/output	Y
Infrared (IR) cut-off filter	Y
Dynamic range	120 dB
Design
Form factor	Bullet (shape)
Mounting type	Ceiling/Wall/Pole
Product colour	White
Housing material	Metal
International Protection (IP) code	IP67
Camera
Minimum illumination	0.0005 Lux
Angle of rotation	360 °
Lens viewing angle, horizontal	95 °
Lens viewing angle, vertical	51 °
Tilt angle range	0 - 75 °
Lens viewing angle, diagonal	115 °
Pan range	0 - 360 °
Camera shutter speed	1/3 - 1/10000 s
Image sensor
Sensor type	CMOS
Optical sensor size	1/1.79 "
Progressive scan	Y
Lens system
Number of lenses	1
Detect distance	76 m
Observe distance	29 m
Recognize distance	14 m
Maximum aperture number	1
Identify distance	7 m
Fixed focal length	4 mm
Night vision
Night vision	Y
Night vision distance	30 m
LED type	IR/White
Number of illumination LEDs	2
Infra-red wavelength	850 nm
Video
Maximum resolution	2688 x 1520 Pixels
Total megapixels	4 MP
Video compression formats	H.264, H.264+, H.265, H.265+
Supported graphics resolutions	320 x 240, 352 x 288, 640 x 360, 640 x 480 (VGA), 704 x 576, 848 x 480, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520
Video streaming	Y
Noise reduction	Y
Noise reduction technology	3D noise reduction
Highlight Compensation (HLC)	Y
Region of Interest (ROI) encoding	Y
Smart IR	Y
Back Light Compensation (BLC)	Y
Bit rate	Main Stream: 256 Kbps - 6 Mbps; Sub-Stream: 64 Kbps - 1024 Kbps
Bit rate control	Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Audio
Built-in speaker(s)	Y
Audio system	2-way
Built-in microphone	Y
Signal-to-Noise Ratio (SNR)	52 dB
Network
Ethernet LAN	Y
Wi-Fi	N
Bluetooth	N
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP, RTMP
Storage
Built-in HDD	N
Card reader integrated	Y
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	512 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Technical details
Compliance certificates	BSMI, CE, Federal Communications Commission (FCC), Industry Canada (IC), KC, VCCI
Security
Alarm input channels	1
Password protection	Y
Alarm output channels	1
Video motion detection	Y
Intelligent Video Surveillance (IVS) system features	Abandoned object, Abnormal sound detection, Human detection, Intrusion, Line crossing detection, Region entrance detection, Region exiting detection, Scene change, Vehicle detection
Active tampering alarm	Y
Digest authentication	Y
IP address filtering	Y
HTTPS encryption	Y
Management features
Web browser	Y
Cloud-managed	Y
Power
Power source type	DC, PoE
DC output voltage	12
Operational conditions
Operating temperature (T-T)	-30 - 60 °C
Storage temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	0 - 95 procent
Storage relative humidity (H-H)	0 - 95 procent
Weight & dimensions
Diameter	66 mm
Length	191 mm
Weight	600 g
Packaging content
Number of cameras	1
Mounting kit	Y
Manual	Y
