See True Colors and Details in the Dark

Unveiling every detail in the dark, experiencing clarity and color as vivid as daylight — no extra fill lights needed.

Worry-Free Night Surveillance: Beyond IR & Full-Color

Eliminates general night vision issues like dark corners, glare, and color loss — enjoy worry-free nighttime monitoring.

See Vividly — Even No Extra Fill Lights Needed

Enables full-color imaging in low-light conditions without fill-in lighting, reducing both energy consumption and insect-triggered false alarms for a more eco-friendly solution.

People or Vehicle Triggered Intelligent IR-White Lights Reveal More in Total Darkness

In complete darkness with zero illumination, VIGI’s intelligent infrared-white lights will automatically activate white lights upon detecting people or vehicles, delivering vivid color imaging while deterring intruders.

Accurate Detection with Clear and Extended Vision

Ideal for Low-Light Conditions Where Colors and Details Matter

VIGI AI Detection Technology

People & Vehicle Attributes Analytics: Search and filter to people or vehicle of interest based on many different attributes, like hair length, topwear color, vehicle type, making post-event search faster and easier

Human & Vehicle Classification: Distinguish humans and vehicles from other objects, such as moving animals, falling leaves, changing lights, and receive more accurate event notifications

Smart Video Enhancement Technology
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.

Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.

3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.

White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.

Efficient H.265+ Compression Technology

H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.

Specification

Product
Product id	1009210
Brand	TP-Link
Partnr	INSIGHT S445S(2.8MM)
EAN/UPC code	8885020625622
Warranty (months)	3 year limited warranty
Performance
Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
Auto pan mode	Y
Wide Dynamic Range (WDR)	Y
Day/night mode	Y
Alarm input/output	Y
Infrared (IR) cut-off filter	Y
Certification	CE, NTRA, VCCI, KC, IC, BSMI, FCC, IP67, ONVIF
Dynamic range	120 dB
Design
Form factor	Dome
Mounting type	Ceiling/Wall
Product colour	White
Housing material	Metal
International Protection (IP) code	IP67
Weatherproof	Y
Camera
Minimum illumination	0.0005 Lux
Angle of rotation	360 °
Lens viewing angle, horizontal	112.5 °
Lens viewing angle, vertical	61.4 °
Tilt angle range	0 - 75 °
Lens viewing angle, diagonal	137 °
Pan range	0 - 360 °
White balance	Area white balance
Camera shutter type	Electronic
Camera shutter speed	1/3 - 1/10000 s
Number of Privacy masking areas	4
Image sensor
Sensor type	CMOS
Optical sensor size	1/79 "
Progressive scan	Y
Panoramic camera
Signal-to-Noise Ratio (SNR) (panoramic camera)	52 dB
Sensor type (panoramic camera)	CMOS
Lens system
Number of lenses	1
Detect distance	59 m
Observe distance	25 m
Recognize distance	12 m
Fixed focus	Y
Maximum aperture number	1
Identify distance	6 m
Fixed focal length	2.8 mm
Night vision
Night vision	Y
Infra-red wavelength	850 nm
Video
Maximum resolution	2688 x 1520 Pixels
Total megapixels	4 MP
Video formats supported	H.264, H.264+, H.265, H.265+
Video compression formats	H.264, H.264+, H.265, H.265+
Supported graphics resolutions	320 x 240, 352 x 288, 640 x 360, 640 x 480 (VGA), 704 x 576, 848 x 480, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520
Video recording	Y
Video streaming	Y
Thermal frame rate (NTSC)	50 Hz
Noise reduction	Y
Thermal frame rate (PAL)	60 Hz
Highlight Compensation (HLC)	Y
Region of Interest (ROI) encoding	Y
Smart IR	Y
Frame rate	30 fps
Back Light Compensation (BLC)	Y
Bit rate	64 Kbit/s
Image quality adjustment	Brightness, Contrast, DNR, Saturation, Sharpness
Bit rate control	Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Audio
Built-in speaker(s)	Y
Audio system	2-way
Audio input channels	2.0
Audio output channels	2.0 kanalen
Built-in microphone	Y
Number of microphones	1
Bit rate range	256 - 6000 Kbit/s
Network
Ethernet LAN	Y
Networking standards	IEEE 802.1x, IEEE 802.3at
Supported network protocols	TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP, RTMP
Live view	Y
Number of simultaneous live view channels	3 kanalen
Storage
Built-in HDD	N
Card reader integrated	Y
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	512 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Microphone in	Y
Technical details
Compliance certificates	CE
Security
Alarm input channels	1
Password protection	Y
Alarm output channels	1
Password protection type	User
Video motion detection	Y
Intelligent Video Surveillance (IVS) system features	Abandoned object, Abnormal sound detection, Intrusion, Line crossing detection, People counting, Region entrance detection, Region exiting detection, Scene change, Vehicle detection
Motion sensor	Y
Mirror	Y
Human and vehicle targets classification	Y
Alert notification type	E-mail, Push notification
Active tampering alarm	Y
Digest authentication	Y
IP address filtering	Y
HTTPS encryption	Y
Management features
Web-based management	Y
Web browser	Y
Cloud-managed	Y
Reset button	Y
Cloud services supported	FTP
Behavior analysis	Audio exception detection, Object removal detection
Power
Power source type	DC, PoE
AC input voltage	12 V
Power consumption (typical)	15.6 W
Power consumption (max)	17.9 W
Operational conditions
Operating temperature (T-T)	-30 - 60 °C
Storage temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	0 - 95 procent
Storage relative humidity (H-H)	0 - 95 procent
Weight & dimensions
Width	111 mm
Depth	111 mm
Height	81.4 mm
Weight	550 g
Package type	Box
Packaging content
Number of cameras	1
Mounting kit	Y
