Product |
Product id
| 959052
|
Brand
| TP-Link
|
Partnr
| VIGI C355(2.8MM)
|
EAN/UPC code
| 4895252506822
|
Warranty (months)
| 3 year limited warranty
|
Performance |
Type
| IP security camera
|
Placement supported
| Outdoor
|
Connectivity technology
| Wired
|
Wide Dynamic Range (WDR)
| Y
|
Day/night mode
| Y
|
Infrared (IR) cut-off filter
| Y
|
Certification
| CE, NTRA, VCCI, KC, BSMI, FCC, IC
|
Dynamic range
| 120 dB
|
Design |
Form factor
| Bullet
|
Mounting type
| Wall
|
Product colour
| White
|
Housing material
| Metal
|
International Protection (IP) code
| IP67
|
Camera |
Minimum illumination
| 0.005 Lux
|
Angle of rotation
| 360 °
|
Lens viewing angle, horizontal
| 111.4 °
|
Lens viewing angle, vertical
| 58.8 °
|
Tilt angle range
| 0 - 90 °
|
Lens viewing angle, diagonal
| 134 °
|
Pan range
| 0 - 360 °
|
Camera shutter speed
| 1/3 to 1/10000 s
|
Number of Privacy masking areas
| 4
|
Image sensor |
Sensor type
| CMOS
|
Optical sensor size
| 1/2.7 "
|
Lens system |
Number of lenses
| 1
|
Detect distance
| 64 m
|
Observe distance
| 27 m
|
Recognize distance
| 13 m
|
Maximum aperture number
| 1.6
|
Identify distance
| 6 m
|
Focal length range
| 2.8 mm
|
Fixed focal length
| 4 mm
|
Night vision |
Night vision
| Y
|
Night vision distance
| 30 m
|
LED type
| IR/White
|
Infra-red wavelength
| 850 nm
|
Video |
Maximum resolution
| 2880 x 1620 Pixels
|
Total megapixels
| 5 MP
|
Video compression formats
| H.264, H.264+, H.265, H.265+
|
Supported graphics resolutions
| 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2688 x 1520, 2880 x 1620
|
Noise reduction
| Y
|
Noise reduction technology
| 3D noise reduction
|
Highlight Compensation (HLC)
| Y
|
Privacy masking
| Y
|
Region of Interest (ROI) encoding
| Y
|
Smart IR
| Y
|
Frame rate
| 30 fps
|
Back Light Compensation (BLC)
| Y
|
Bit rate
| 6 Mbps
|
Image quality adjustment
| Brightness, Contrast, Mirror, Saturation, Sharpness
|
Bit rate control
| Constant Bit Rate (CBR), Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
|
Audio |
Built-in speaker(s)
| Y
|
Audio system
| 2-way
|
Audio formats supported
| G.711
|
Built-in microphone
| Y
|
Sample rate
| 8 kHz
|
Signal-to-Noise Ratio (SNR)
| 52 dB
|
Network |
Ethernet LAN
| Y
|
Wi-Fi
| N
|
Bluetooth
| N
|
Ethernet interface type
| Fast Ethernet
|
Supported network protocols
| TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
|
Storage |
Built-in HDD
| N
|
Card reader integrated
| Y
|
Compatible memory cards
| MicroSD (TransFlash)
|
Maximum memory card size
| 512 GB
|
Ports & interfaces |
Ethernet LAN (RJ-45) ports
| 1
|
DC-in jack
| Y
|
Security |
Password protection
| Y
|
Privacy protection
| Y
|
Digest authentication
| Y
|
IP address filtering
| Y
|
Management features |
Web browser
| Y
|
Power |
Power source type
| DC, PoE
|
Power consumption (max)
| 10.7 W
|
DC output voltage
| 12
|
Operational conditions |
Operating temperature (T-T)
| -30 - 60 °C
|
Storage temperature (T-T)
| -40 - 60 °C
|
Operating relative humidity (H-H)
| 0 - 95 procent
|
Storage relative humidity (H-H)
| 0 - 95 procent
|
Weight & dimensions |
Width
| 184 mm
|
Height
| 74 mm
|
Length
| 74 mm
|
Weight
| 525 g
|
Packaging content |
Number of cameras
| 1
|
